IKA EasySyn 5000 Advanced Reactor system Synthesis Reactor
EasySyn is the reactor system for organic or aqueous syntheses
It ensures safe and reproducible chemical reactions on the way from laboratory to pilot scale
Our EasySyn 5000 Advanced package comprises a complete reactor system for use in the laboratory
You can also control it with the IKA lab software labworldsoft® 6 to automate all processes
The high quality of the used materials allows operation at temperatures from -50 to 200 °C and up to a negative pressure of 3 mbar
EasySyn Advanced includes the LT 5.40 draining set
With its special valves, it enables fast and clean draining of the tempering fluid from the double jacket and easy replacement of the reactor vessel
EasySyn 5000 Advanced also includes:
Ergonomically designed stand system for quick and easy replacement of the reactor vessels and adjustment of the working height to your body size
DN 150 vessel clamp for holding the reactor vessel
Double-walled 5000 ml reaction vessel made of chemically resistant borosilicate 3.3 glass with bottom discharge valve
Spring-loaded valve spindle of the drain valve to prevent glass breakage
Reactor lid with various openings (1 x NS 29/32 center glass joint, 2 x NS 29/32, 1 x NS 14/23) for flexible adaptation to the desired application
DN 150 clamp ring and DN 150 FEP-coated O-ring to ensure chemical resistance
Powerful overhead stirrer EUROSTAR 100 control with 100 Ncm, including keyless chuck for easy and fast mounting of the stirring tool
Additional functions such as timer, overload protection and temperature measurement integrated in the overhead stirrer
PTFE-coated propeller stirrer for optimum mixing and chemical resistance
High-quality stirrer guide for vacuum operation up to 3 mbar
Drainage set LT 5.40 with valves and temperature control hoses for easy draining of the double-walled reactor vessel and for fast changing of the reactor vessels
RS 232 interface on the stirrer for external control using our lab automation software labworldsoft® 6, available as an accessory
Further reactor vessels (with and without bottom discharge), reactor covers, stirring tools, temperature sensors, circulators, laboratory automation and much more can be found in the " Accessories" section
To complete your system, you get all the complementary components from a single source: overhead stirrers, circulators, vacuum pumps and controllers, sensors and automation software
All from IKA and all perfectly matched to each other
Would you like your own desired configuration? Or do you need an offer? You are welcome to contact our sales team
Note: The scope of delivery does not include temperature hoses for connecting a thermostat
| Volume [l] | 5 |
| Flange dimension | DN150 |
| Vacuum application | yes |
| Working temperature [°C] | -50 - 200 |
| Useable volume min. [ml] | 1000 |
| Useable volume with temperature probe min. [ml] | 1500 |
| Attainable vacuum [mbar] | 3 |
| Dimensions (W x H x D) [mm] | 500 x 950 x 580 |
| RS 232 interface | yes |
| USB interface | yes |
EasySyn is the reactor system for organic or aqueous syntheses
It ensures safe and reproducible chemical reactions on the way from laboratory to pilot scale
Our EasySyn 5000 Advanced package comprises a complete reactor system for use in the laboratory
You can also control it with the IKA lab software labworldsoft® 6 to automate all processes
The high quality of the used materials allows operation at temperatures from -50 to 200 °C and up to a negative pressure of 3 mbar
EasySyn Advanced includes the LT 5.40 draining set
With its special valves, it enables fast and clean draining of the tempering fluid from the double jacket and easy replacement of the reactor vessel
EasySyn 5000 Advanced also includes:
Ergonomically designed stand system for quick and easy replacement of the reactor vessels and adjustment of the working height to your body size
DN 150 vessel clamp for holding the reactor vessel
Double-walled 5000 ml reaction vessel made of chemically resistant borosilicate 3.3 glass with bottom discharge valve
Spring-loaded valve spindle of the drain valve to prevent glass breakage
Reactor lid with various openings (1 x NS 29/32 center glass joint, 2 x NS 29/32, 1 x NS 14/23) for flexible adaptation to the desired application
DN 150 clamp ring and DN 150 FEP-coated O-ring to ensure chemical resistance
Powerful overhead stirrer EUROSTAR 100 control with 100 Ncm, including keyless chuck for easy and fast mounting of the stirring tool
Additional functions such as timer, overload protection and temperature measurement integrated in the overhead stirrer
PTFE-coated propeller stirrer for optimum mixing and chemical resistance
High-quality stirrer guide for vacuum operation up to 3 mbar
Drainage set LT 5.40 with valves and temperature control hoses for easy draining of the double-walled reactor vessel and for fast changing of the reactor vessels
RS 232 interface on the stirrer for external control using our lab automation software labworldsoft® 6, available as an accessory
Further reactor vessels (with and without bottom discharge), reactor covers, stirring tools, temperature sensors, circulators, laboratory automation and much more can be found in the " Accessories" section
To complete your system, you get all the complementary components from a single source: overhead stirrers, circulators, vacuum pumps and controllers, sensors and automation software
All from IKA and all perfectly matched to each other
Would you like your own desired configuration? Or do you need an offer? You are welcome to contact our sales team
Note: The scope of delivery does not include temperature hoses for connecting a thermostat
