IKA SY 1000 Reactor vessel

Merk: IKA

Referentie: 0020113461

Double-walled reactor vessel including accessories for the EasySyn reactor system

Volume: 1000 ml

Flange size: DN 100

Including stainless steel metal adapter M 16x1 (Male) to connect temperature hoses

Scope of delivery:

Glasreactor incl

metal adapter

Meer lezen

€1.487,00 Excl. BTW

€1.799,27 Incl. BTW

Levertijd op aanvraag

Gratis levering v.a. € 400 in webshop

Voordelige prijzen

Vijfsterrenservice voor & na verkoop

Levering 1 à 3 dagen voor stockartikelen

Technische data

Volume [l]	1
Fill level diameter ratio	1.25
Fill level at Neeminal volume [mm]	96
Vessel inner diameter [mm]	120
Vessel outer diameter [mm]	160
Height (room dimension) [mm]	251
Width (room dimension) [mm]	218
Depth (room dimension) [mm]	165
Flange type	acc. DIN 12214 with circular groove
Flange dimension	DN100
Flange collar diameter [mm]	108
Bottom shape	Torispherical head
Bottom drain	Nee
Tempering jacket filling capacity [L ]	0.71
Tempering jacket inlet connection	DN 15 (tech-flange)
Tempering jacket inlet inner diameter [mm]	15
Vacuum application	Ja
Tempering jacket outlet connection	DN 15 (tech-flange)
Tempering jacket oulet inner diameter [mm]	15
Thread closure system	M16x1
Width across flats	WAF 22
Material closure system	stainless steel 1.4404
Reactor vessel material	borosilicate glass 3.3 DIN ISO 3585
Working temperature [°C]	-50 - 230
Useable volume [ml]	120 - 1150
Useable volume with temperature probe min. [ml]	260
Pressure max.	atmospheric pressure
Attainable vacuum [mbar]	3
Material in contact with medium	borosilicate glass 3.3 DIN ISO 3585
