Powerful disperser for volumes ranging from 1 – 2, 000 ml (H2O) with digital speed display
Its wide speed range of 600 – 25, 000 rpm allows for work with high circumferential speeds
An extensive selection of dispersing shafts makes multiple applications possible
The application range includes homogenization and dispersion tasks for use under vacuum in the IKA laboratory reactors
Digital speed display
Electronic speed control
Electronic overload protection
Fast and simple cleaning of stainless steel dispersing shafts
Error code display
Quiet operation
Snelheidsbereik (tpm) | 600 - 25.000 rpm | |||||||||||||||||||||||||||||||||||||||||||||||||
Volume van het monster | 2 L | |||||||||||||||||||||||||||||||||||||||||||||||||
Technische data |
Motor rating input [W] | 800 |
Motor rating output [W] | 500 |
Volume range (H2O) [l] | 0.001 - 2 |
Viscosity max. [mPas] | 5000 |
Speed range [rpm] | 600 - 25000 |
Speed deviation [%] | 1 |
Speed adjustment | stepless |
Speed display | LED |
Noise without element [dB(A)] | 75 |
Extension arm diameter [mm] | 13 |
Extension arm length [mm] | 160 |
Process type | batch |
Timer | Nee |
Permissible ON time [%] | 100 |
Dimensions (W x H x D) [mm] | 87 x 271 x 106 |
Weight [kg] | 2.5 |
Permissible ambient temperature [°C] | 5 - 40 |
Permissible ambient conditions | 80% (up to 31°C), decreasing linearly to max. 50 (@40°C) |
Protection class according to DIN EN 60529 | IP 20 |
RS 232 interface | Nee |
USB interface | Nee |
Analog output | Nee |
Voltage [V] | 220 - 240 |
Frequency [Hz] | 50/60 |
Power input [W] | 800 |
Powerful disperser for volumes ranging from 1 – 2, 000 ml (H2O) with digital speed display
Its wide speed range of 600 – 25, 000 rpm allows for work with high circumferential speeds
An extensive selection of dispersing shafts makes multiple applications possible
The application range includes homogenization and dispersion tasks for use under vacuum in the IKA laboratory reactors
Digital speed display
Electronic speed control
Electronic overload protection
Fast and simple cleaning of stainless steel dispersing shafts
Error code display
Quiet operation
Toebehoren
Downloads
ika-dispersers-brochure-en.pdf
