Ika S 25 KD – LR – 25 F Dispersing tool
The S 25 KD - LR - 25 F dispersing tool was specially developed to use with the IKA laboratory reactors
It is slightly longer than the standard dispersing tools, allowing for a deeper tool immersion within the reactors and the processing of even lower minimum sample volumes
In addition, this tool can be used in conjunction with vacuum conditions of up to 50 mbar
The F tool is able to achieve an even finer ultimate particle size compared to the G tools
Tool disassembly for cleaning and maintenance is made simpler with this new design
Compatible with: T 25 digital, T 25 easy clean digital, T 25 easy clean control
| Geschikt voor | T 25 digital; T 25 easy clean digital; T 25 easy clean control | |||||||||||||||||||||||||||||||||||||
| Werkbereik | 100 - 2.000 ml | |||||||||||||||||||||||||||||||||||||
| Technische data |
| Volume range (H2O) [l] | 0.1 - 2 |
| Stator diameter [mm] | 25 |
| Rotor diameter [mm] | 18 |
| Gap between rotor and stator [mm] | 0.5 |
| allowable Speed max. [rpm] | 25000 |
| Circumferential speed max. [m/s] | 23.6 |
| Immersion depth [mm] | 40 - 220 |
| Shaft length [mm] | 267 |
| Material in contact with medium | FFPM, PTFE, AISI316L |
| pH range | 2 - 13 |
| Suitable for solvents | Nee |
| Suitable for abrasive substances | Nee |
| Working temperature max. [°C] | 150 |
| Sterilization methods | wet chemical |
| Vacuum [mbar] | 100 |
| Ultimate fineness, suspensions [µm] | 5 - 25 |
| Ultimate fineness, emulsions [µm] | 1 - 5 |
| Weight [kg] | 0.404 |
| Permissible ambient temperature [°C] | 5 - 40 |
The S 25 KD - LR - 25 F dispersing tool was specially developed to use with the IKA laboratory reactors
It is slightly longer than the standard dispersing tools, allowing for a deeper tool immersion within the reactors and the processing of even lower minimum sample volumes
In addition, this tool can be used in conjunction with vacuum conditions of up to 50 mbar
The F tool is able to achieve an even finer ultimate particle size compared to the G tools
Tool disassembly for cleaning and maintenance is made simpler with this new design
Compatible with: T 25 digital, T 25 easy clean digital, T 25 easy clean control
