Universally used strong laboratory stirrer for quantities up to 40 l (H2O)
It automatically adjusts the speed through microprocessor controlled technology within the speed range of 0/30 - 2000 rpm
Safety circuits installed ensures automatic cut-off in an anti-stall or overload conditions
Continuous comparison of shaft speed to desired speed is maintained and variations are adjusted automatically
This guarantees a constant speed even with changes in viscosities of the sample
Digital speed display
Infinitely adjustable speed
Push-through agitator shafts
Overload protection
Short-term overload operation
Slim casing
Quiet operation
Error code display
Max. koppel (Ncm) | 60 Ncm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. viscositeit (mPas) | 50.000 mPas | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. volume vloeistof | 40 L | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Rotatiesnelheid (tpm) | 0 - 2.000 rpm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Technische data |
Stirring quantity max. per stirring position (H2O) [l] | 40 |
Motor rating input [W] | 176 |
Motor rating output [W] | 126 |
Motor principle | Brushless DC |
Speed display | 7 segment LED |
Speed range [rpm] | 0/30 - 2000 |
Reversible direction of rotation | Nee |
Intermittent operation | Nee |
Viscosity max. [mPas] | 50000 |
Output max. at stirring shaft [W] | 126 |
Permissible ON time [%] | 100 |
Torque max. at stirring shaft [Ncm] | 60 |
Speed adjustment | stepless |
Setting accuracy speed [rpm] | ±1 |
Deviation of speed measurement n > 300rpm [%] | ±1 |
Deviation of speed measurement n < 300rpm [rpm] | ±3 |
Stirring element fastening | chuck |
Temperature display | Nee |
Chuck range diameter [mm] | 0.5 - 10 |
Hollow shaft, inner diameter [mm] | 11 |
Hollow shaft (push-through - when stopped) | Ja |
Fastening on stand | extension arm |
Extension arm diameter [mm] | 16 |
Extension arm length [mm] | 220 |
Torque display | Nee |
Speed control | electronic |
Nominal torque [Nm] | 0.6 |
Timer | Nee |
Housing material | alu-cast coating / thermoplastic polymer |
Clean room qualified | Nee |
Explosion proofed | Nee |
Dimensions (W x H x D) [mm] | 86 x 248 x 208 |
Weight [kg] | 3.9 |
Permissible ambient temperature [°C] | 5 - 40 |
Permissible relative humidity [%] | 80 |
Protection class according to DIN EN 60529 | IP 42 |
RS 232 interface | Nee |
USB interface | Nee |
Analog output | Nee |
Voltage [V] | 230 |
Frequency [Hz] | 50/60 |
Power input [W] | 176 |
Universally used strong laboratory stirrer for quantities up to 40 l (H2O)
It automatically adjusts the speed through microprocessor controlled technology within the speed range of 0/30 - 2000 rpm
Safety circuits installed ensures automatic cut-off in an anti-stall or overload conditions
Continuous comparison of shaft speed to desired speed is maintained and variations are adjusted automatically
This guarantees a constant speed even with changes in viscosities of the sample
Digital speed display
Infinitely adjustable speed
Push-through agitator shafts
Overload protection
Short-term overload operation
Slim casing
Quiet operation
Error code display
