Ika EUROSTAR 200 control

Merk: IKA
Referentie: 0003992000
Extremely powerful laboratory stirrer for highly viscous applications and intensive mixing for quantities up to 100 l (H2O)
It is designed with a removable wireless controller and a digital TFT display
It automatically adjusts the speed through microprocessor controlled technology within the speed range of 0/6 - 2000 rpm (two speed ranges)
The stirrer comes equipped with a RS 232 and a USB interface to control and document all parameters
An integrated torque trend display is provided for the measurement of viscosity changes
Safety circuits installed ensures automatic cut-off in an anti-stall or overload conditions
Continuous comparison of shaft speed to desired speed is maintained and variations are adjusted automatically
This guarantees a constant speed even with changes in viscosities of the sample
Multilingual TFT display
Programmable functions
Integrated temperature measurement
Interval operation
Timer function
Adjustable safety circuit
Locked function
Infinitely adjustable speed
Push-through agitator shafts
Overload protection
Short-term overload operation
Slim casing
Quiet operation
Error code display
H 67.60 temperature sensor and WH 11 WiCo holder included in delivery
3.982,00 Excl. BTW
4.818,22 Incl. BTW
Levertijd op aanvraag
Gratis levering v.a. € 400 in webshop
Voordelige prijzen
Vijfsterrenservice voor & na verkoop
Levering 1 à 3 dagen voor stockartikelen
Max. koppel (Ncm)200 Ncm
Max. viscositeit (mPas)100.000 mPas
Max. volume vloeistof100 L
Rotatiesnelheid (tpm)0 - 2.000 rpm
Technische data
Stirring quantity max. per stirring position (H2O) [l] 100
Motor rating input [W] 135
Motor rating output [W] 84
Motor principle Brushless DC
Speed display TFT
Speed range [rpm] 0/6 - 2000
Reversible direction of rotation Nee
Intermittent operation Ja
Viscosity max. [mPas] 100000
Output max. at stirring shaft [W] 84
Permissible ON time [%] 100
Torque max. at stirring shaft [Ncm] 200
Torque I max. [Ncm] 200
Torque II max. [Ncm] 40
Speed range I (50 Hz) [rpm] 6 - 400
Speed range II (50 Hz) [rpm] 30 - 2000
Speed range I (60 Hz) [rpm] 6 - 400
Speed range II (60 Hz) [rpm] 30 - 2000
Speed adjustment stepless
Setting accuracy speed [rpm] ±1
Deviation of speed measurement n > 300rpm [%] ±1
Deviation of speed measurement n < 300rpm [rpm] ±3
Stirring element fastening chuck
Connection for ext. temperature sensor PT1000
Temperature display Ja
Plug-in coupling (Ø) [mm] 10
Chuck range diameter [mm] 0.5 - 10
Hollow shaft, inner diameter [mm] 10.3
Hollow shaft (push-through - when stopped) Ja
Fastening on stand extension arm
Extension arm diameter [mm] 16
Extension arm length [mm] 220
Torque display Ja
Speed control electronic
Nominal torque [Nm] 2
Torque measurement trend
Deviation of torque measurement I [Ncm] ±20
Deviation of torque measurement II [Ncm] ±6
Timer Ja
Timer display TFT
Time setting range [min] 1 - 6000
Temperature measuring range [°C] -10 - +350
Temperature measurement resolution [K] 0.1
Accuracy of temperature measurement [K] ±0.5 + tolerance PT1000 (DIN EN 60751 Class A)
Limit deviation temperature sensor [K] ≤ ± (0.15 + 0.002xITI)
Housing material alu-cast coating / thermoplastic polymer
Clean room qualified Nee
Explosion proofed Nee
Communication distance (depend onbuilding) max. [m] 150
Dimensions (W x H x D) [mm] 91 x 297 x 231
Weight [kg] 4.9
Permissible ambient temperature [°C] 5 - 40
Permissible relative humidity [%] 80
Protection class according to DIN EN 60529 IP 40
RS 232 interface Ja
USB interface Ja
Analog output Nee
Voltage [V] 230
Frequency [Hz] 50/60
Power input [W] 130
Extremely powerful laboratory stirrer for highly viscous applications and intensive mixing for quantities up to 100 l (H2O)
It is designed with a removable wireless controller and a digital TFT display
It automatically adjusts the speed through microprocessor controlled technology within the speed range of 0/6 - 2000 rpm (two speed ranges)
The stirrer comes equipped with a RS 232 and a USB interface to control and document all parameters
An integrated torque trend display is provided for the measurement of viscosity changes
Safety circuits installed ensures automatic cut-off in an anti-stall or overload conditions
Continuous comparison of shaft speed to desired speed is maintained and variations are adjusted automatically
This guarantees a constant speed even with changes in viscosities of the sample
Multilingual TFT display
Programmable functions
Integrated temperature measurement
Interval operation
Timer function
Adjustable safety circuit
Locked function
Infinitely adjustable speed
Push-through agitator shafts
Overload protection
Short-term overload operation
Slim casing
Quiet operation
Error code display
H 67.60 temperature sensor and WH 11 WiCo holder included in delivery
