Powerful laboratory stirrer for high viscous applications and intensive mixing for quantities up to 150 l (H2O)
It automatically adjusts the speed within the range of 0/6 – 2000 rpm (two speed ranges) through microprocessor controlled technology
Integrated safety circuits ensure automatic cut-off in an anti-stall or overload conditions
Continuous comparison of shaft to desired speed is performed and variations are adjusted automatically
This ensures constant speed even with changes in viscosities of the sample
-Digital speed display
-Infinitely adjustable speed
-Push-through agitator shafts
-Overload protection
-Short-term overload operation
-Slim casing
-Quiet operation
-Error code display
Max. koppel (Ncm) | 400 Ncm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. viscositeit (mPas) | 100.000 mPas | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. volume vloeistof | 150 L | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Rotatiesnelheid (tpm) | 0 - 2.000 rpm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Technische data |
Stirring quantity max. per stirring position (H2O) [l] | 150 |
Motor rating input [W] | 220 |
Motor rating output [W] | 176 |
Motor principle | Brushless DC |
Speed display | 7 segment LED |
Speed range [rpm] | 0/6 - 2000 |
Reversible direction of rotation | Nee |
Intermittent operation | Nee |
Viscosity max. [mPas] | 100000 |
Output max. at stirring shaft [W] | 167 |
Permissible ON time [%] | 100 |
Torque max. at stirring shaft [Ncm] | 400 |
Torque I max. [Ncm] | 400 |
Torque II max. [Ncm] | 80 |
Speed range I (50 Hz) [rpm] | 6 - 400 |
Speed range II (50 Hz) [rpm] | 30 - 2000 |
Speed range I (60 Hz) [rpm] | 6 - 400 |
Speed range II (60 Hz) [rpm] | 30 - 2000 |
Speed adjustment | stepless |
Setting accuracy speed [rpm] | ±1 |
Deviation of speed measurement n > 300rpm [%] | ±1 |
Deviation of speed measurement n < 300rpm [rpm] | ±3 |
Stirring element fastening | chuck |
Temperature display | Nee |
Chuck range diameter [mm] | 3 - 16 |
Hollow shaft, inner diameter [mm] | 10.3 |
Hollow shaft (push-through - when stopped) | Ja |
Fastening on stand | extension arm |
Extension arm diameter [mm] | 16 |
Extension arm length [mm] | 160 |
Torque display | Nee |
Speed control | electronic |
Nominal torque [Nm] | 4 |
Timer | Nee |
Clean room qualified | Nee |
Explosion proofed | Nee |
Dimensions (W x H x D) [mm] | 114 x 325 x 245 |
Weight [kg] | 8.4 |
Permissible ambient temperature [°C] | 5 - 40 |
Permissible relative humidity [%] | 80 |
Protection class according to DIN EN 60529 | IP 42 |
RS 232 interface | Nee |
USB interface | Nee |
Analog output | Nee |
Voltage [V] | 230 |
Frequency [Hz] | 50/60 |
Power input [W] | 226 |
Powerful laboratory stirrer for high viscous applications and intensive mixing for quantities up to 150 l (H2O)
It automatically adjusts the speed within the range of 0/6 – 2000 rpm (two speed ranges) through microprocessor controlled technology
Integrated safety circuits ensure automatic cut-off in an anti-stall or overload conditions
Continuous comparison of shaft to desired speed is performed and variations are adjusted automatically
This ensures constant speed even with changes in viscosities of the sample
-Digital speed display
-Infinitely adjustable speed
-Push-through agitator shafts
-Overload protection
-Short-term overload operation
-Slim casing
-Quiet operation
-Error code display
