Ika EUROSTAR 100 digital
Powerful laboratory stirrer for highly viscous applications and intensive mixing for quantities up to 100 l (H2O)
It automatically adjusts the speed through microprocessor controlled technology within the speed range of 0/30 – 1300 rpm
Safety circuits installed ensures automatic cut-off in an anti-stall or overload conditions
Continuous comparison of shaft speed to desired speed is maintained and variations are adjusted automatically
This guarantees a constant speed even with changes in viscosities of the sample
Digital speed display
Infinitely adjustable speed
Push-through agitator shafts
Overload protection
Short-term overload operation
Slim casing
Quiet operation
Error code display
| Max. koppel (Ncm) | 100 Ncm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Max. viscositeit (mPas) | 70.000 mPas | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Max. volume vloeistof | 100 L | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Rotatiesnelheid (tpm) | 0 - 1.300 rpm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Technische data |
| Stirring quantity max. per stirring position (H2O) [l] | 100 |
| Motor rating input [W] | 186 |
| Motor rating output [W] | 136 |
| Motor principle | Brushless DC |
| Speed display | 7 segment LED |
| Speed range [rpm] | 0/30 - 1300 |
| Reversible direction of rotation | Nee |
| Intermittent operation | Nee |
| Viscosity max. [mPas] | 70000 |
| Output max. at stirring shaft [W] | 136 |
| Permissible ON time [%] | 100 |
| Torque max. at stirring shaft [Ncm] | 100 |
| Speed adjustment | stepless |
| Setting accuracy speed [rpm] | ±1 |
| Deviation of speed measurement n > 300rpm [%] | ±1 |
| Deviation of speed measurement n < 300rpm [rpm] | ±3 |
| Stirring element fastening | chuck |
| Temperature display | Nee |
| Chuck range diameter [mm] | 0.5 - 10 |
| Hollow shaft, inner diameter [mm] | 11 |
| Hollow shaft (push-through - when stopped) | Ja |
| Fastening on stand | extension arm |
| Extension arm diameter [mm] | 16 |
| Extension arm length [mm] | 220 |
| Torque display | Nee |
| Speed control | electronic |
| Nominal torque [Nm] | 1 |
| Timer | Nee |
| Housing material | alu-cast coating / thermoplastic polymer |
| Clean room qualified | Nee |
| Explosion proofed | Nee |
| Dimensions (W x H x D) [mm] | 86 x 248 x 208 |
| Weight [kg] | 3.9 |
| Permissible ambient temperature [°C] | 5 - 40 |
| Permissible relative humidity [%] | 80 |
| Protection class according to DIN EN 60529 | IP 42 |
| RS 232 interface | Nee |
| USB interface | Nee |
| Analog output | Nee |
| Voltage [V] | 230 |
| Frequency [Hz] | 50/60 |
| Power input [W] | 186 |
Powerful laboratory stirrer for highly viscous applications and intensive mixing for quantities up to 100 l (H2O)
It automatically adjusts the speed through microprocessor controlled technology within the speed range of 0/30 – 1300 rpm
Safety circuits installed ensures automatic cut-off in an anti-stall or overload conditions
Continuous comparison of shaft speed to desired speed is maintained and variations are adjusted automatically
This guarantees a constant speed even with changes in viscosities of the sample
Digital speed display
Infinitely adjustable speed
Push-through agitator shafts
Overload protection
Short-term overload operation
Slim casing
Quiet operation
Error code display
Toebehoren
Downloads
ika-overhead-stirrers-brochure-en.pdf
