The RV 3 Rotary Evaporator is the manual basic model in the family of IKA Rotation Evaporators
It finds a multitude of uses in the chemical, pharmaceutical, and biotechnology industries, in research and development, in manufacturing and quality assurance, in laboratories, and in plant construction
Digital displays for speed and heating bath temperature enable optimum control of all distillation processes
New: 4l heating bath
integrated safety lift-out function in case of power failure
water/oil heating bath with carrying handles
locking button for fixing heating bath temperature
locking mechanism: red indicator shows unlocked position of the vapor tube
flask clamping mechanism with integrated push-off function for easy exchange of evaporation flasks
manual lift for precise positioning of the glassware
adjustable immersion angle
single-handed manual lift handling, suitable for left and tight-handed operators
speed range: 5 - 300 min-1
low device voltage (24V) ensures user safety
compatible with the entire range of IKA RV 10 glassware
Package description: With heating bath HB eco and RV 10.4 Dry Ice Condenser
Glaswerk | Nee | |||||||||||||||||||||||||||||||||||||||||||
Max. temperatuur (°C) | 99 °C | |||||||||||||||||||||||||||||||||||||||||||
Motorlift (ja/nee) | Nee | |||||||||||||||||||||||||||||||||||||||||||
Technische data |
Type of cooling | Dry ice condenser |
Cooling surface [cm2] | 620 |
Motor principle | DC |
Speed range [rpm] | 20 - 300 |
Reversible direction of rotation | Nee |
Speed tolerance set rotation speed < 100rpm [rpm] | ±1 |
Speed tolerance set rotation speed > 100rpm [%] | ±1 |
Lift | manual |
Stroke [mm] | 150 |
Heating temperature range [°C] | room temp. - 99 |
Timer | Nee |
Dimensions (W x H x D) [mm] | 440 x 530 x 330 |
Weight [kg] | 28.3 |
Permissible ambient temperature [°C] | 5 - 40 |
Permissible relative humidity [%] | 80 |
Protection class according to DIN EN 60529 | IP 20 |
RS 232 interface | Nee |
USB interface | Nee |
Analog output | Nee |
Voltage [V] | 100 - 240 |
Frequency [Hz] | 50/60 |
Power input [W] | 1400 |
The RV 3 Rotary Evaporator is the manual basic model in the family of IKA Rotation Evaporators
It finds a multitude of uses in the chemical, pharmaceutical, and biotechnology industries, in research and development, in manufacturing and quality assurance, in laboratories, and in plant construction
Digital displays for speed and heating bath temperature enable optimum control of all distillation processes
New: 4l heating bath
integrated safety lift-out function in case of power failure
water/oil heating bath with carrying handles
locking button for fixing heating bath temperature
locking mechanism: red indicator shows unlocked position of the vapor tube
flask clamping mechanism with integrated push-off function for easy exchange of evaporation flasks
manual lift for precise positioning of the glassware
adjustable immersion angle
single-handed manual lift handling, suitable for left and tight-handed operators
speed range: 5 - 300 min-1
low device voltage (24V) ensures user safety
compatible with the entire range of IKA RV 10 glassware
Package description: With heating bath HB eco and RV 10.4 Dry Ice Condenser
