Ika RC 2 GREEN basic
Powerful, compact and energy-efficient circulating chiller for cooling applications up to -30 °C
The on-demand and speed-controlled compressor, operated with natural refrigerant, achieves a cooling capacity of 800 W at a minimum energy consumption
The speed-controlled PEEK pump allows an indirect continuous adjustment of maximum pressure and flow rate
The integrated filling funnel and drain valve enable safe and clean handling of the thermofluid
With regular cleaning, the easily accessible stainless steel woven mesh air filter guarantees consistent performance
The high-quality insulated 4 l bath reservoir allows the use of up to 2.5 l of thermofluid in the external cooling circle without refilling
highly efficient speed-controlled cooling unit with a cooling capacity of 800 W (@20 °C)
natural refrigerant R290
speed-controlled PEEK pump: (0.5 bar - 21 l/min)
digital level indicator
big LED-Display
optical and acoustic warning functions
easy-to-clean stainless steel mesh filter
high quality insulated 4 l bath reservoir (minimum 1.5 l)
Interfaces:
RS 232 and USB for controlling and monitoring the devices via labworldsoft® and to update the software online
Calibrateable internal temperature sensor (3 point)
| Afkoelingsvermogen (W) | 800 W | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Debiet (L/min) | 21 L/min | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Temperatuurbereik (°C) | -30 - +70 °C | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Technische data |
| Appliance type | Recirculating chiller |
| Cooling agent | R290 |
| Cooling agent quantity [g] | 69 |
| Cooling agent pressure max. [bar] | 21 |
| Cooling capacity (@20°C) [W] | 800 |
| Cooling capacity (@10°C) [W] | 700 |
| Cooling capacity (@0°C) [W] | 500 |
| Cooling capacity (@-10°C) [W] | 400 |
| Cooling capacity (@-20°C) [W] | 200 |
| Cooling capacity (@-30°C) [W] | 90 |
| Working temperature [°C] | -30 - room temp. |
| Operating temperature min. [°C] | -30 |
| Operating temperature max. (with external heating) [°C] | 70 |
| Temperature display | Ja |
| Temperature stability DIN 12876 (@-10°C) [K] | ±0.15 |
| Working temperature sensor | PT 100 |
| Working temperature display | LED |
| Safety temperature display | LED |
| Temperature stability DIN 12876 [K] | ±0.15 |
| Display resolution [K] | 0.1 |
| Set temperature resolution [K] | ±0.1 |
| Warning function optical | Ja |
| Warning function acoustic | Ja |
| Warning function excess temperature | Ja |
| Warning function insufficient temperature | Nee |
| Sub-level protection | Ja |
| Over-level protection | Ja |
| Filling volume [l] | 1.4 - 4.0 |
| Pump type | Pressure- / suction pump |
| Pump capacity adjustable | Ja |
| Pump pressure max. (0 liters discharge flow) [bar] | 0.5 |
| Pressure pump (suction side) (0 liter flow) [bar] | 0.25 |
| Flow rate max. (0 bar back pressure) [l/min] | 21 |
| Pump connection | M16x1 |
| Calibration option | Ja |
| Technical data complies with the standard | DIN 12876 |
| Noise level [dB(A)] | 61 |
| Dimensions (W x H x D) [mm] | 220 x 475 x 525 |
| Weight [kg] | 25.5 |
| Permissible ambient temperature [°C] | 5 - 32 |
| Permissible relative humidity [%] | 80 |
| Protection class according to DIN EN 60529 | IP 21 |
| RS 232 interface | Ja |
| USB interface | Ja |
| Voltage [V] | 230 |
| Frequency [Hz] | 50/60 |
| Power input [W] | 350 |
Powerful, compact and energy-efficient circulating chiller for cooling applications up to -30 °C
The on-demand and speed-controlled compressor, operated with natural refrigerant, achieves a cooling capacity of 800 W at a minimum energy consumption
The speed-controlled PEEK pump allows an indirect continuous adjustment of maximum pressure and flow rate
The integrated filling funnel and drain valve enable safe and clean handling of the thermofluid
With regular cleaning, the easily accessible stainless steel woven mesh air filter guarantees consistent performance
The high-quality insulated 4 l bath reservoir allows the use of up to 2.5 l of thermofluid in the external cooling circle without refilling
highly efficient speed-controlled cooling unit with a cooling capacity of 800 W (@20 °C)
natural refrigerant R290
speed-controlled PEEK pump: (0.5 bar - 21 l/min)
digital level indicator
big LED-Display
optical and acoustic warning functions
easy-to-clean stainless steel mesh filter
high quality insulated 4 l bath reservoir (minimum 1.5 l)
Interfaces:
RS 232 and USB for controlling and monitoring the devices via labworldsoft® and to update the software online
Calibrateable internal temperature sensor (3 point)
