IKA VCV 1 Vacuum control valve manual
Allows for adjusting the set vacuum value on the manual manometer
VC 10.400 stand not included in the scope of delivery, available as accessory (ID no
0035001735)
| Technische data |
| Connection diameter suction side [mm] | 8 |
| Connection diameter pressure side [mm] | 8 |
| Input pressure [mbar] | 1 - 1050 |
| Boiling point detection | Nee |
| Solvent library | Nee |
| Two-point control | Nee |
| Analog speed vacuum control | Nee |
| Pressure unit / scale | mbar |
| Vacuum sensor | Nee |
| Control range [mbar] | 1 - 1050 |
| Resolution pressure [mbar] | 50 |
| Measurement uncertainty [mbar] | 25 |
| Medium temperature (gas) [°C] | 5 - 40 |
| Vacuum valve | Nee |
| Venting valve | Ja |
| Material in contact with medium | Al2O3, PP, stainless steel |
| Housing material | PP |
| Fastening | stand / clamp |
| Dimensions (W x H x D) [mm] | 65 x 255 x 140 |
| Weight [kg] | 0.6 |
| Permissible ambient temperature [°C] | 0 - 40 |
| Permissible relative humidity [%] | 80 |
| Protection class according to DIN EN 60529 | IP 65 |
Allows for adjusting the set vacuum value on the manual manometer
VC 10.400 stand not included in the scope of delivery, available as accessory (ID no
0035001735)
