IKA Dispergeerder T 18 mini digital ULTRA-TURRAX
Dispergeerelement niet bij de levering inbegrepen
T 18 mini digital is an economical high-performance dispersing instrument with a wide speed range of 3000 - 25,000 rpm for working volumes of up to 1.5 liters (H20)
It enables the user to work at high circumferential speeds even with small rotor diameters
The compact design of this disperser allows for operation in the tightest of spaces
A large TFT display ensures easy readability from a greater distance, even from outside a fume hood
This setup is best suited for simple applications homogenizing samples with low viscosity
A broad choice of dispersing elements guarantee a wide range of applications for efficient emulsification, homogenization, dispersing and suspending as well as reduction of particle sizes to the micrometer range
Digital speed display and adjustment
Brushless motor for improved motor lifetime, quieter operation and more hygienic applications
Timer function for unattended operation
Dispersing elements: stainless steel option with a high chemical resistance or plastic options that come in two sizes
Quick insert for easy change of dispersing elements for convenient cleaning and maintenance
USB interface for remote control and parameter documentation with the IKA labworldsoft® software
All S 18 dispersing tools and accessories are compatible with this the T 18 mini digital
Ontdek alle modellen in deze serie: T 18 brushless digital ULTRA-TURRAX®, T 18 digital ULTRA-TURRAX®, T 10 basic ULTRA-TURRAX®, T 25 easy clean control ULTRA-TURRAX®, T 25 easy clean digital ULTRA-TURRAX®, UTL 25 digital Inline ULTRA-TURRAX®, T 25 digital ULTRA-TURRAX®, T 65 digital ULTRA-TURRAX®, T 50 digital ULTRA-TURRAX®, T 25 digital package Ultra-Turrax Disperser, T 18 digital package ULTRA-TURRAX Disperser, T 25 mini control ULTRA-TURRAX, T 18 mini digital ULTRA-TURRAX
| Motor rating input [W] | 210 |
| Motor rating output [W] | 160 |
| Volume range (H2O) [l] | 0.001 - 1.5 |
| Viscosity max. [mPas] | 2000 |
| Speed range [rpm] | 3000 - 25000 |
| Reversible direction of rotation | no |
| Speed deviation [%] | 3 |
| Speed display | LED |
| Speed adjustment | stepless |
| Noise without element [dB(A)] | 75 |
| Motor principle | Brushless DC |
| Extension arm diameter [mm] | 13 |
| Extension arm length [mm] | 160 |
| Process type | batch |
| Temperature display | no |
| Timer | yes |
| Timer display | LED |
| Permissible ON time [%] | 100 |
| Dimensions (W x H x D) [mm] | 66 x 186 x 100 |
| Weight [kg] | 1.8 |
| Permissible ambient temperature [°C] | 5 - 40 |
| Permissible relative humidity [%] | 80 |
| Protection class according to DIN EN 60529 | IP 30 |
| RS 232 interface | no |
| USB interface | yes |
| Bluetooth interface | no |
| WiFi Interface | no |
| Analog output | no |
| Voltage [V] | 100 - 240 |
| Frequency [Hz] | 50/60 |
| Power input [W] | 210 |
| Power input max. [W] | 250 |
| Power input standby [W] | 3 |
| DC Voltage [V=] | 48 |
| Current consumption [mA] | 4500 |
Dispergeerelement niet bij de levering inbegrepen
T 18 mini digital is an economical high-performance dispersing instrument with a wide speed range of 3000 - 25,000 rpm for working volumes of up to 1.5 liters (H20)
It enables the user to work at high circumferential speeds even with small rotor diameters
The compact design of this disperser allows for operation in the tightest of spaces
A large TFT display ensures easy readability from a greater distance, even from outside a fume hood
This setup is best suited for simple applications homogenizing samples with low viscosity
A broad choice of dispersing elements guarantee a wide range of applications for efficient emulsification, homogenization, dispersing and suspending as well as reduction of particle sizes to the micrometer range
Digital speed display and adjustment
Brushless motor for improved motor lifetime, quieter operation and more hygienic applications
Timer function for unattended operation
Dispersing elements: stainless steel option with a high chemical resistance or plastic options that come in two sizes
Quick insert for easy change of dispersing elements for convenient cleaning and maintenance
USB interface for remote control and parameter documentation with the IKA labworldsoft® software
All S 18 dispersing tools and accessories are compatible with this the T 18 mini digital
Ontdek alle modellen in deze serie: T 18 brushless digital ULTRA-TURRAX®, T 18 digital ULTRA-TURRAX®, T 10 basic ULTRA-TURRAX®, T 25 easy clean control ULTRA-TURRAX®, T 25 easy clean digital ULTRA-TURRAX®, UTL 25 digital Inline ULTRA-TURRAX®, T 25 digital ULTRA-TURRAX®, T 65 digital ULTRA-TURRAX®, T 50 digital ULTRA-TURRAX®, T 25 digital package Ultra-Turrax Disperser, T 18 digital package ULTRA-TURRAX Disperser, T 25 mini control ULTRA-TURRAX, T 18 mini digital ULTRA-TURRAX
