IKA RV 8 with Dry Ice Condenser, coated Rotatieverdamper
The IKA Rotary Evaporator range gets a new family member - the RV 8
This new distilling system completes the existing series by adding a functional basic model
The manual lift, with ambidextrous design, allows for precise positioning of the glassware
Digital displays for rotation speed and heating bath temperature allow for optimal control of all distilling processes
New clamp mechanism to simplify the changing of evaporation flasks
Manual lift with integrated safety “lift-out-function“
New clamp mechanism
Water/oil heating bath with integrated ergonomic carrying handles
Key-button with locking function for the heating bath temperature
Speed range 5 - 300 rpm
Single-hand operation - ambidextrous design
Adjustable immersion angle
Additional user safety through reduced 24 V power requirements within the unit
Compatible with the complete range of IKA RV 10 glassware
Package description: With heating bath HB digital and RV 10.40 Dry Ice Condenser coated
| Glaswerk | Ja (met coating) | |||||||||||||||||||||||||||||||||||||||||||||||||||||
| Max. temperatuur (°C) | 180 °C | |||||||||||||||||||||||||||||||||||||||||||||||||||||
| Max. Volume (L) | 4 L | |||||||||||||||||||||||||||||||||||||||||||||||||||||
| Motorlift (ja/nee) | Nee | |||||||||||||||||||||||||||||||||||||||||||||||||||||
| Verwarmingsvermogen (W) | 1.400 W | |||||||||||||||||||||||||||||||||||||||||||||||||||||
| Technische data |
| Type of cooling | Dry ice condenser |
| Cooling surface [cm2] | 620 |
| Motor principle | DC |
| Speed range [rpm] | 5 - 300 |
| Reversible direction of rotation | Nee |
| Speed tolerance set rotation speed < 100rpm [rpm] | ±1 |
| Speed tolerance set rotation speed > 100rpm [%] | ±1 |
| Lift | manual |
| Stroke [mm] | 120 |
| Heating temperature range [°C] | room temp. - 180 |
| Heat output [W] | 1400 |
| Set temperature resolution [K] | ±1 |
| Filling volume max. [l] | 4 |
| Vacuum controller integrated | Nee |
| Timer | Nee |
| Dimensions (W x H x D) [mm] | 510 x 490 x 345 |
| Weight [kg] | 25.76 |
| Permissible ambient temperature [°C] | 5 - 40 |
| Permissible relative humidity [%] | 80 |
| Protection class according to DIN EN 60529 | IP 20 |
| RS 232 interface | Nee |
| USB interface | Nee |
| Analog output | Nee |
| Voltage [V] | 100 - 240 |
| Frequency [Hz] | 50/60 |
| Power input [W] | 1500 |
| DC Voltage [V=] | 24 |
The IKA Rotary Evaporator range gets a new family member - the RV 8
This new distilling system completes the existing series by adding a functional basic model
The manual lift, with ambidextrous design, allows for precise positioning of the glassware
Digital displays for rotation speed and heating bath temperature allow for optimal control of all distilling processes
New clamp mechanism to simplify the changing of evaporation flasks
Manual lift with integrated safety “lift-out-function“
New clamp mechanism
Water/oil heating bath with integrated ergonomic carrying handles
Key-button with locking function for the heating bath temperature
Speed range 5 - 300 rpm
Single-hand operation - ambidextrous design
Adjustable immersion angle
Additional user safety through reduced 24 V power requirements within the unit
Compatible with the complete range of IKA RV 10 glassware
Package description: With heating bath HB digital and RV 10.40 Dry Ice Condenser coated
