The RV 10 digital pro V double Complete package is the complete solution for your rotary evaporator setup with two rotary evaporators.
In addition to the two RV 10 digital V rotary evaporators, incl
HB digital heating bath and a highly efficient vertical glass condenser set with 1L receiver and evaporator flask, the package includes the VACSTAR digital vacuum pump, two VC 10 pro vacuum controllers and the RC 2 GREEN basic recirculating chiller
All components and connections required for operation are included.
RV 10 digital is a robust and reliable lab companion
Its optimized bath volume allows for fast heat-up times
The condenser unit has special designed glass tubes that utilize the 1500 cm² surface extremely efficient
That’s why the RV 10 digital delivers reliable and reproducible process results that are usually reserved for more costly systems
Additional features such as smooth start, left-right interval or timer function capability support the user in their daily lab work
Another important aspect of the RV 10 digital are the sophisticated safety features
The motorized lift has an automated lift-out function in case of power outage to prevent superheating of the solvent
Safety temperature circuits can be set individually
Dry-run protection, adjustable lower end stop and lock function of bath setting complete the line of safety features
The RS 232 interface allows for remote control via the software labworldsoft®
The heating bath is controlled from the main unit via the IR interface.
The included VACSTAR digital vacuum pump is extremely space-saving and achieves a minimum vacuum of 2 mbar
One vacuum source is sufficient to supply both rotary evaporators
Controlling is done with the help of the two included vacuum controllers VC 10 pro
The powerful and at the same time energy-efficient RC 2 GREEN basic recirculating chiller is suitable for cooling tasks down to -30 °C
The demand- and speed-controlled compressor, which is operated with natural refrigerant R290, achieves a cooling capacity of 800 W with minimum energy input.
Glaswerk | Ja | |||||||||||||||||||||||||||||||||||||||||||||||||
Max. temperatuur (°C) | 180 °C | |||||||||||||||||||||||||||||||||||||||||||||||||
Max. Volume (L) | 3 L | |||||||||||||||||||||||||||||||||||||||||||||||||
Motorlift (ja/nee) | Ja | |||||||||||||||||||||||||||||||||||||||||||||||||
Verwarmingsvermogen (W) | 1.300 W | |||||||||||||||||||||||||||||||||||||||||||||||||
Technische data |
Type of cooling | vertical |
Cooling surface [cm2] | 1600 |
Motor principle | DC |
Speed range [rpm] | 5 - 280 |
Reversible direction of rotation | Ja |
Lift | Motor |
Stroke [mm] | 140 |
Heating temperature range [°C] | room temp. - 180 |
Heat output [W] | 1300 |
Set temperature resolution [K] | ±1 |
Filling volume max. [l] | 3 |
Vacuum controller integrated | Ja |
Measurement accuracy +/- [mbar] | 2 |
Vacuum adjustment range [mbar] | 1050 - 1 |
Vacuum measurement range [mbar] | 1050 - 1 |
Timer | Ja |
Dimensions (W x H x D) [mm] | 500 x 430 x 440 |
Weight [kg] | 21.5 |
Permissible ambient temperature [°C] | 5 - 40 |
Permissible relative humidity [%] | 80 |
Protection class according to DIN EN 60529 | IP 20 |
RS 232 interface | Ja |
Voltage [V] | 220 - 240 |
Frequency [Hz] | 50/60 |
Power input [W] | 1400 |
The RV 10 digital pro V double Complete package is the complete solution for your rotary evaporator setup with two rotary evaporators.
In addition to the two RV 10 digital V rotary evaporators, incl
HB digital heating bath and a highly efficient vertical glass condenser set with 1L receiver and evaporator flask, the package includes the VACSTAR digital vacuum pump, two VC 10 pro vacuum controllers and the RC 2 GREEN basic recirculating chiller
All components and connections required for operation are included.
RV 10 digital is a robust and reliable lab companion
Its optimized bath volume allows for fast heat-up times
The condenser unit has special designed glass tubes that utilize the 1500 cm² surface extremely efficient
That’s why the RV 10 digital delivers reliable and reproducible process results that are usually reserved for more costly systems
Additional features such as smooth start, left-right interval or timer function capability support the user in their daily lab work
Another important aspect of the RV 10 digital are the sophisticated safety features
The motorized lift has an automated lift-out function in case of power outage to prevent superheating of the solvent
Safety temperature circuits can be set individually
Dry-run protection, adjustable lower end stop and lock function of bath setting complete the line of safety features
The RS 232 interface allows for remote control via the software labworldsoft®
The heating bath is controlled from the main unit via the IR interface.
The included VACSTAR digital vacuum pump is extremely space-saving and achieves a minimum vacuum of 2 mbar
One vacuum source is sufficient to supply both rotary evaporators
Controlling is done with the help of the two included vacuum controllers VC 10 pro
The powerful and at the same time energy-efficient RC 2 GREEN basic recirculating chiller is suitable for cooling tasks down to -30 °C
The demand- and speed-controlled compressor, which is operated with natural refrigerant R290, achieves a cooling capacity of 800 W with minimum energy input.
