The dispersing tool S 25 EC - C - 25 G is suitable for general applications involving high speed and high shear mixing, crushing in liquid, emulsification, particle size reduction in solution and vigorous dissolving of miscible and immiscible solids and liquids in a liquid medium
As the name "easy clean" implies, the dispersing tools are particularly easy to clean: by simply turning and lowering the clamp, the shaft and rotor can be extended from the shaft until the whole rotor comes out of the stator
Then the shaft tube of the tool can be completely rinsed from inside
Note: S 25 EC - C - 25 G is only compatible with the dispersers T 25 easy clean digital and control
The temperature sensing function of the T tools can only be activated when used in combination with the T 25 easy clean control
Compatibilité | T 25 easy clean digital; T 25 easy clean control | |||||||||||||||||||||||||||||||||||
Plage de travail | 50 - 2.000 ml | |||||||||||||||||||||||||||||||||||
Données techniques |
Capacité traitée (H2O) [l] | 0.05 - 2 |
Diamètre du sator [mm] | 25 |
Diamètre du rotor [mm] | 17 |
Interstice stator-rotor [mm] | 0.5 |
Vitesse admissible max. [rpm] | 25000 |
Vitesse périphérique [m/s] | 22.2 |
Profondeur d'immersion [mm] | 35 - 150 |
Longueur totale [mm] | 191 |
Matériel en contact avec le produit | AISI 316L, céramique |
pH | 2 - 13 |
Résiste aux solvants | oui |
Résiste aux abrasifs | oui |
Température de travail max. [°C] | 180 |
Méthodes de stérilisation | toutes méthodes |
Finesse finale, suspension [µm] | 15 - 50 |
Finesse finale, émulsions [µm] | 1 - 10 |
Poids [kg] | 0.4 |
Plage de température du milieu admise [°C] | 5 - 40 |
The dispersing tool S 25 EC - C - 25 G is suitable for general applications involving high speed and high shear mixing, crushing in liquid, emulsification, particle size reduction in solution and vigorous dissolving of miscible and immiscible solids and liquids in a liquid medium
As the name "easy clean" implies, the dispersing tools are particularly easy to clean: by simply turning and lowering the clamp, the shaft and rotor can be extended from the shaft until the whole rotor comes out of the stator
Then the shaft tube of the tool can be completely rinsed from inside
Note: S 25 EC - C - 25 G is only compatible with the dispersers T 25 easy clean digital and control
The temperature sensing function of the T tools can only be activated when used in combination with the T 25 easy clean control
