Crushing without cross-contamination - this is possible with the MultiDrive control package including autoclavable disposable tubes MT 150 and the required TC 1 protective housing for dry samples
MT 150 is a disposable tube with a typical stainless steel beater
The plastic milling tube can be autoclaved
This effectively prevents cross-contamination even if it is used multiple times
An integrated RFID chip simultaneously stores and limits the lifespan of the milling tube
5 spare seals are included in the scope of delivery
By replacing the seal, the service life of the grinding chamber can be extended
The disposable tube can only be operated with the TC 1 protective housing which is also included in the scope of delivery
MultiDrive universal crusher can perform a wide range of crushing tasks involving coarse and fine crushing, thanks to the variety of vessels available
There is a USB interface available for easy actuation and documentation respectively
High performance
Excellent crushing performance is guaranteed by a combination of
variable rotational speeds, ranging from 3000 rpm to 20 000 rpm,
and a 1000 Watt output
Interval operation
The option of interval programming is simple to activate at the
press of a button
Interval operation is an asset during the coarse
crushing of hard samples or for extra thorough blending
Integrated cooling
A cooling system is integrated in the milling cup, which allows
indirect heat dissipation
Thus, coolant and sample remain separate
TFT-display
A clear TFT-display guarantees user-friendly operation
Temperature measurement
MultiDrive control offers temperature measurement and vessel
recognition using RFID
A temperature limit can be set for
temperature-sensitive materials, or for specific planned reactions to
protect against overheating
Weighing function
The weighing function is also integrated into the user-friendly
workflow of the IKA MultiDrive control
Weighing is performed
before crushing using the same mixing cup, so that no transfer
of contents is required
Volume utile max (ml) | Selon bol | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Broyeur ou accessoires (Tubes, Billes, hélice) | Broyeur | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Vitesse max. | 20.000 rpm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Type de broyeur (découpage/impact/à billes) | Broyeur | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Données techniques |
Type de fonctionnement | batch |
Système de travail | Couper/broyer/mélanger/disperser |
Puissance du moteur absorbée [W] | 1000 |
Puissance du moteur débitée [W] | 800 |
Plage de vitesse [rpm] | 3000 - 20000 |
Écart de vitesse [%] | ±5 |
Durée de fonctionnement MARCHE [min] | 5 |
Durée de fonctionnement ARRET [min] | 10 |
Système du moteur | DC sans brosse |
Affichage | TFT |
Unité de lecture/écriture RFID | oui |
Affichage de la température | oui |
Résolution de réglage de thermométrie [K] | 0.1 |
Précision de la mesure [K] | ±1 |
Limite de température min. [°C] | -50 |
Limite de température max. [°C] | 120 |
Suivi du temps de maintien | oui |
Fonction de pesage | oui |
Plage de pesage [g] | 5 - 4000 |
résolution du pesage [g] | 1 |
Capacité de charge max. de la fonction de pesage [kg] | 4 |
Exactitude de pesage | ± (0,3 % +2) g |
Détection des récipients | oui |
Programmation de rampe | oui |
Dimensions (L x H x P) [mm] | 300 x 350 x 250 |
Poids [kg] | 8.5 |
Plage de température du milieu admise [°C] | 5 - 40 |
Humidité relative admissible [%] | 80 |
Protection selon DIN EN 60529 | IP 31 |
Interface numérique USB | oui |
Interface numérique Bluetooth | oui |
Tension [V] | 220 - 240 |
Fréquence [Hz] | 50/60 |
Puissance absorbée de l'appareil [W] | 1000 |
Crushing without cross-contamination - this is possible with the MultiDrive control package including autoclavable disposable tubes MT 150 and the required TC 1 protective housing for dry samples
MT 150 is a disposable tube with a typical stainless steel beater
The plastic milling tube can be autoclaved
This effectively prevents cross-contamination even if it is used multiple times
An integrated RFID chip simultaneously stores and limits the lifespan of the milling tube
5 spare seals are included in the scope of delivery
By replacing the seal, the service life of the grinding chamber can be extended
The disposable tube can only be operated with the TC 1 protective housing which is also included in the scope of delivery
MultiDrive universal crusher can perform a wide range of crushing tasks involving coarse and fine crushing, thanks to the variety of vessels available
There is a USB interface available for easy actuation and documentation respectively
High performance
Excellent crushing performance is guaranteed by a combination of
variable rotational speeds, ranging from 3000 rpm to 20 000 rpm,
and a 1000 Watt output
Interval operation
The option of interval programming is simple to activate at the
press of a button
Interval operation is an asset during the coarse
crushing of hard samples or for extra thorough blending
Integrated cooling
A cooling system is integrated in the milling cup, which allows
indirect heat dissipation
Thus, coolant and sample remain separate
TFT-display
A clear TFT-display guarantees user-friendly operation
Temperature measurement
MultiDrive control offers temperature measurement and vessel
recognition using RFID
A temperature limit can be set for
temperature-sensitive materials, or for specific planned reactions to
protect against overheating
Weighing function
The weighing function is also integrated into the user-friendly
workflow of the IKA MultiDrive control
Weighing is performed
before crushing using the same mixing cup, so that no transfer
of contents is required
