IKA RW 47 digital Bovenroerder
Extremely powerful, mechanically controlled laboratory stirrer designed for highly viscous applications for quantities up to 200 l (H2O)
It is suitable for intensive mixing for use in laboratories and pilot plants
The stirrer comes equipped with a protection for overheating of the motor by means of self-locking temperature limiter
Additionally, a stirring shaft protection (R 303) and a clamping fixture (R 6547.1) to secure mixing vessels are available as accessories
Digital speed display
Infinitely adjustable speed (57
1300 rpm) in two speed ranges
Overload protection
Error code display
Robust, ergonomic design
Quiet operation
With constant power-drive
SI 400 safety switch and SI 474 fixing device are available as optional accessories allowing the user to switch on the instrument only at a defined height in the stand’s working range
The device requires a 3-phase electricity supply and power cord (not included in scope of delivery) in order to operate
The connection of the unit to the power supply must be done by a qualified electrician
Wiring diagrams are included in the manual for reference
| Stirring quantity max. per stirring position (H2O) [l] | 200 |
| Motor rating input [W] | 511 |
| Motor rating output [W] | 370 |
| Motor principle | three-phase current |
| Speed display | LED |
| Speed range [rpm] | 57 - 1300 |
| Viscosity max. [mPas] | 100000 |
| Output max. at stirring shaft [W] | 300 |
| Permissible ON time [%] | 100 |
| Torque max. at stirring shaft [Ncm] | 3000 |
| Torque max. at stirring shaft at 60 1/min (overload) [Ncm] | 4642 |
| Torque max. at stirring shaft at 100 1/min [Ncm] | 3000 |
| Torque max. at stirring shaft at 1.000 1/min [Ncm] | 285 |
| Torque I max. [Ncm] | 3000 |
| Torque II max. [Ncm] | 620 |
| Speed range I (50 Hz) [rpm] | 57 - 275 |
| Speed range II (50 Hz) [rpm] | 275 - 1300 |
| Speed adjustment | stepless |
| Setting accuracy speed [rpm] | ±1 |
| Deviation of speed measurement [rpm] | ±10 |
| Stirring element fastening | chuck |
| Chuck range diameter [mm] | 3 - 16 |
| Hollow shaft, inner diameter [mm] | 13 |
| Hollow shaft (push-through - when stopped) | no |
| Fastening on stand | flange |
| Torque display | no |
| Speed control | mechanical |
| Nominal torque [Nm] | 30 |
| Housing material | alu-cast coating / thermoplastic polymer |
| Clean room qualified | no |
| Explosion proofed | no |
| Dimensions (W x H x D) [mm] | 145 x 478 x 358 |
| Weight [kg] | 16.6 |
| Permissible ambient temperature [°C] | 5 - 40 |
| Permissible relative humidity [%] | 80 |
| Protection class according to DIN EN 60529 | IP 54 |
| RS 232 interface | no |
| USB interface | no |
| Analog output | no |
| Voltage [V] | 3 x 400 |
| Frequency [Hz] | 50 |
| Power input [W] | 513 |
Extremely powerful, mechanically controlled laboratory stirrer designed for highly viscous applications for quantities up to 200 l (H2O)
It is suitable for intensive mixing for use in laboratories and pilot plants
The stirrer comes equipped with a protection for overheating of the motor by means of self-locking temperature limiter
Additionally, a stirring shaft protection (R 303) and a clamping fixture (R 6547.1) to secure mixing vessels are available as accessories
Digital speed display
Infinitely adjustable speed (57
1300 rpm) in two speed ranges
Overload protection
Error code display
Robust, ergonomic design
Quiet operation
With constant power-drive
SI 400 safety switch and SI 474 fixing device are available as optional accessories allowing the user to switch on the instrument only at a defined height in the stand’s working range
The device requires a 3-phase electricity supply and power cord (not included in scope of delivery) in order to operate
The connection of the unit to the power supply must be done by a qualified electrician
Wiring diagrams are included in the manual for reference
