Ika ElectraSyn 2.0 pro Package

Merk: IKA
Referentie: 0040003261
ElectraSyn 2.0 is a three-in-one device that runs electrosynthesis, cyclic voltammetry (CV), and room temperature stirring
Its beginner-friendly features allow synthetic chemist to run simple CV and explore the substrate’s electrochemical properties - set up constant current or constant voltage reactions in the most intuitive way
We constantly strive to further optimize our devices for you
That is why our development never stops
The device keeps evolving with software development which enables state-of-art functionalities benefitting scientific discovery
Accessories are widely available in order to support the expanded functionalities
The IKA ElectraSyn App (available for both iPhone and Android) enables reaction and CV experiment monitoring, data transfer, and various other functions
The CV package is included in the pro package
4.780,00 Excl. BTW
5.783,80 Incl. BTW
Levertijd op aanvraag
Gratis levering v.a. € 400 in webshop
Voordelige prijzen
Vijfsterrenservice voor & na verkoop
Levering 1 à 3 dagen voor stockartikelen
Technische data
Nominal voltage (input) [VDC] 48
Current max. (input) [mA] 1500
Voltage output (electrode) [V] 30/10
Current output (electrode) [mA] 100
Motor rating output [W] 9
Speed range [rpm] 50 - 1500
Setting accuracy speed [rpm] 10
Stirring quantity max. per stirring position (H2O) [l] 0.1
Stirring bar length [mm] 8 - 16
Speed adjustment Turning kNeeb
Display TFT
Output current resolution [mA] 0.1
Output voltage resolution [V] 0.01
Current measuring resolution [mA] 0.1
Voltage measuring resolution [V] 0.1
Current measuring accuracy [mA] ±0.1
Voltage measuring accuracy [V] ±0.01
Dimensions (W x H x D) [mm] 130 x 150 x 250
Weight [kg] 3.55
Permissible ambient temperature [°C] 5 - 50
Permissible relative humidity [%] 80
Protection class according to DIN EN 60529 IP 40
RS 232 interface Nee
USB interface Ja
Analog output Nee
Voltage [V] 100 - 240
Frequency [Hz] 50/60
Power input [W] 39.84
Power input standby [W] 5
DC Voltage [V=] 48
Current consumption [mA] 750
ElectraSyn 2.0 is a three-in-one device that runs electrosynthesis, cyclic voltammetry (CV), and room temperature stirring
Its beginner-friendly features allow synthetic chemist to run simple CV and explore the substrate’s electrochemical properties - set up constant current or constant voltage reactions in the most intuitive way
We constantly strive to further optimize our devices for you
That is why our development never stops
The device keeps evolving with software development which enables state-of-art functionalities benefitting scientific discovery
Accessories are widely available in order to support the expanded functionalities
The IKA ElectraSyn App (available for both iPhone and Android) enables reaction and CV experiment monitoring, data transfer, and various other functions
The CV package is included in the pro package
