Ika ElectraSyn 2.0 Package
ElectraSyn 2.0 is a three-in-one device that runs electrosynthesis, cyclic voltammetry (CV), and room temperature stirring
Its beginner-friendly features allow synthetic chemist to run simple CV and explore the substrate’s electrochemical properties - set up constant current or constant voltage reactions in the most intuitive way
We constantly strive to further optimize our devices for you
That is why our development never stops
The device keeps evolving with software development which enables state-of-art functionalities benefitting scientific discovery
Accessories are widely available in order to support the expanded functionalities
The IKA ElectraSyn App (available for both iPhone and Android) enables reaction and CV experiment monitoring, data transmitting, and various other functions
The CV package is not included in the standard package
| Technische data |
| Nominal voltage (input) [VDC] | 48 |
| Current max. (input) [mA] | 1500 |
| Voltage output (electrode) [V] | 30/10 |
| Current output (electrode) [mA] | 100 |
| Motor rating output [W] | 9 |
| Speed range [rpm] | 50 - 1500 |
| Setting accuracy speed [rpm] | 10 |
| Stirring quantity max. per stirring position (H2O) [l] | 0.1 |
| Stirring bar length [mm] | 8 - 16 |
| Speed adjustment | Turning kNeeb |
| Display | TFT |
| Output current resolution [mA] | 0.1 |
| Output voltage resolution [V] | 0.01 |
| Current measuring resolution [mA] | 0.1 |
| Voltage measuring resolution [V] | 0.1 |
| Current measuring accuracy [mA] | ±0.1 |
| Voltage measuring accuracy [V] | ±0.01 |
| Dimensions (W x H x D) [mm] | 130 x 150 x 250 |
| Weight [kg] | 3.72 |
| Permissible ambient temperature [°C] | 5 - 50 |
| Permissible relative humidity [%] | 80 |
| Protection class according to DIN EN 60529 | IP 40 |
| RS 232 interface | Nee |
| USB interface | Ja |
| Analog output | Nee |
| Voltage [V] | 100 - 240 |
| Frequency [Hz] | 50/60 |
| Power input [W] | 39.84 |
| Power input standby [W] | 5 |
| DC Voltage [V=] | 48 |
| Current consumption [mA] | 750 |
ElectraSyn 2.0 is a three-in-one device that runs electrosynthesis, cyclic voltammetry (CV), and room temperature stirring
Its beginner-friendly features allow synthetic chemist to run simple CV and explore the substrate’s electrochemical properties - set up constant current or constant voltage reactions in the most intuitive way
We constantly strive to further optimize our devices for you
That is why our development never stops
The device keeps evolving with software development which enables state-of-art functionalities benefitting scientific discovery
Accessories are widely available in order to support the expanded functionalities
The IKA ElectraSyn App (available for both iPhone and Android) enables reaction and CV experiment monitoring, data transmitting, and various other functions
The CV package is not included in the standard package
