Ika S 25 EC – C – 25 G – ST Dispersing tool
The dispersing tool S 25 EC-C-25G-ST is particularly suitable for dispersing applications in the field of food analysis, e.g
the dispersion of meat or vegetables in liquid
The easy clean dispersing tool is particularly easy to clean: By turning and lowering the clamp, the shaft and rotor can be dropped down till the whole rotor comes out of the stator
Then the shaft tube of the tool can also be completely rinsed from inside
Type of bearing: Ceramic plain bearing
Product-touching material: AISL 316L, ceramics
Solvent suitable: Yes
Sterilizable: Yes, all methods
Max
working temperature [°C]: 180
Shaft length [mm]: 191
Dameter stator / rotor [mm]: 25 / 20
Gap between [mm]: 0.5
Recommend emersion depth [mm]: 35 - 150
Recommend working range [mL]: 50 - 2000
S 25 EC-C-25G-ST is only compatible with the dispersers T 25 easy clean digital and control.
| Geschikt voor | T 25 easy clean digital; T 25 easy clean control | |||||||||||||||||||||||||||||||||||
| Werkbereik | 50 - 2.000 ml | |||||||||||||||||||||||||||||||||||
| Technische data |
| Volume range (H2O) [l] | 0.05 - 2 |
| Stator diameter [mm] | 25 |
| Rotor diameter [mm] | 20 |
| Gap between rotor and stator [mm] | 0.5 |
| allowable Speed max. [rpm] | 25000 |
| Circumferential speed max. [m/s] | 26.2 |
| Immersion depth [mm] | 35 - 150 |
| Shaft length [mm] | 191 |
| Material in contact with medium | AISI 316L, ceramic |
| pH range | 2 - 13 |
| Suitable for solvents | Ja |
| Suitable for abrasive substances | Ja |
| Working temperature max. [°C] | 180 |
| Sterilization methods | all methods |
| Ultimate fineness, suspensions [µm] | 15 - 50 |
| Ultimate fineness, emulsions [µm] | 1 - 10 |
| Weight [kg] | 0.4 |
| Permissible ambient temperature [°C] | 5 - 40 |
The dispersing tool S 25 EC-C-25G-ST is particularly suitable for dispersing applications in the field of food analysis, e.g
the dispersion of meat or vegetables in liquid
The easy clean dispersing tool is particularly easy to clean: By turning and lowering the clamp, the shaft and rotor can be dropped down till the whole rotor comes out of the stator
Then the shaft tube of the tool can also be completely rinsed from inside
Type of bearing: Ceramic plain bearing
Product-touching material: AISL 316L, ceramics
Solvent suitable: Yes
Sterilizable: Yes, all methods
Max
working temperature [°C]: 180
Shaft length [mm]: 191
Dameter stator / rotor [mm]: 25 / 20
Gap between [mm]: 0.5
Recommend emersion depth [mm]: 35 - 150
Recommend working range [mL]: 50 - 2000
S 25 EC-C-25G-ST is only compatible with the dispersers T 25 easy clean digital and control.
