IKA S 25 EC – C – 18 G – ST Dispergeerelement
Dispersing tool S 25 EC-C-18G-ST is only compatible with the dispersers T 25 easy clean digital &
control
Cleaning status for easy clean tool: By turning and lowering the clamp, the shaft and rotor can be dropped down till the whole rotor comes out of the stator
Then the shaft tube of the tool can also be completely rinsed inside
Type of bearing: Ceramic plain bearing
Product-touching material: AISL 316L, ceramics
Solvent suitable: Yes
Sterilizable: Yes, all methods
Max
working temperature [°C]: 180
Shaft length [mm]: 191
Diameter stator / rotor [mm]: 18 / 13.4
Gap between [mm]: 0.25
Recommend emersion depth [mm]: 35
150
Recommend working range [mL]: 10
1500
| Volume range (H2O) [l] | 0.01 - 1.5 |
| Stator diameter [mm] | 18 |
| Rotor diameter [mm] | 13.4 |
| Gap between rotor and stator [mm] | 0.25 |
| allowable Speed max. [rpm] | 25000 |
| Circumferential speed max. [m/s] | 17.5 |
| Immersion depth [mm] | 35 - 150 |
| Shaft length [mm] | 191 |
| Material in contact with medium | AISI 316L, ceramic |
| pH range | 2 - 13 |
| Suitable for solvents | yes |
| Suitable for abrasive substances | yes |
| Working temperature max. [°C] | 180 |
| Sterilization methods | all methods |
| Ultimate fineness, suspensions [µm] | 10 - 50 |
| Ultimate fineness, emulsions [µm] | 1 - 10 |
| Weight [kg] | 0.4 |
| Permissible ambient temperature [°C] | 5 - 40 |
Dispersing tool S 25 EC-C-18G-ST is only compatible with the dispersers T 25 easy clean digital &
control
Cleaning status for easy clean tool: By turning and lowering the clamp, the shaft and rotor can be dropped down till the whole rotor comes out of the stator
Then the shaft tube of the tool can also be completely rinsed inside
Type of bearing: Ceramic plain bearing
Product-touching material: AISL 316L, ceramics
Solvent suitable: Yes
Sterilizable: Yes, all methods
Max
working temperature [°C]: 180
Shaft length [mm]: 191
Diameter stator / rotor [mm]: 18 / 13.4
Gap between [mm]: 0.25
Recommend emersion depth [mm]: 35
150
Recommend working range [mL]: 10
1500
Downloads
ika-dispergeerelementen-brochure-en.pdf
