IKA MS 3 control Vortex schudder
Compact, universal small shaker suitable for shaking tasks with all small vessels and microtiter plates
Wide range of attachments
Attachment detection
Timer with countdown function
Stable in all speed ranges
Sturdy zinc die cast casing
USB connection for remote control
Continuous or touch operation (with standard attachment)
Two operating modes:
Mode A (safe mode with attachment detection):
The maximum speed of 3,000 rpm is only reached with the standard attachment in touch mode
When using other attachments the speed is limited to 1,300 rpm
Mode B (without attachment detection):
A speed of 3,000 rpm is possible with all attachments, depending on the application (see accessory list in the manual)
| Type of movement | orbital |
| Shaking stroke [mm] | 4.5 |
| Permissible shaking weight (incl. attachment) [kg] | 0.5 |
| Motor rating input [W] | 10 |
| Motor rating output [W] | 8 |
| Permissible ON time [%] | 100 |
| Speed min (adjustable) [rpm] | 100 |
| Speed range [rpm] | 100 - 3000 |
| Speed display | LCD |
| Speed deviation [%] | 1 |
| Timer | yes |
| Timer display | LCD |
| Time setting min. [s] | 1 |
| Time setting max. [min] | 3599 |
| Deviation device clock max. [%] | 1 |
| Operating mode | timer and continuous operation |
| Touch function | yes |
| Shaking table lock | no |
| Working with microtiter plates | yes |
| Number of microtiter plates | 1 |
| Dimensions (W x H x D) [mm] | 148 x 63 x 205 |
| Weight [kg] | 3.16 |
| Permissible ambient temperature [°C] | 5 - 40 |
| Permissible relative humidity [%] | 80 |
| Protection class according to DIN EN 60529 | IP 21 |
| RS 232 interface | yes |
| Analog output | no |
| Voltage [V] | 100 - 240 |
| Frequency [Hz] | 50/60 |
| Power input [W] | 20 |
| DC Voltage [V=] | 24 |
| Current consumption [mA] | 800 |
Compact, universal small shaker suitable for shaking tasks with all small vessels and microtiter plates
Wide range of attachments
Attachment detection
Timer with countdown function
Stable in all speed ranges
Sturdy zinc die cast casing
USB connection for remote control
Continuous or touch operation (with standard attachment)
Two operating modes:
Mode A (safe mode with attachment detection):
The maximum speed of 3,000 rpm is only reached with the standard attachment in touch mode
When using other attachments the speed is limited to 1,300 rpm
Mode B (without attachment detection):
A speed of 3,000 rpm is possible with all attachments, depending on the application (see accessory list in the manual)
