VACUUBRAND Complete controller built-in version VACUU·SELECT
The VACUU·SELECT complete controller provides enhanced process efficiency to applications supported by a vacuum source such as a basic pump or a powerful vacuum network
The VACUU·SELECT controller has you covered
Use manual set-point-control for simple processes, run pre-defined applications at the touch of a button, or create your own application with simple drag-and-drop editing
The controller is available as a benchtop unit, ready for mounting on lab scaffolding, or as a built-in version for lab casework
The integrated controller includes the VACUU·SELECT vacuum controller, a check valve, and a chemical-resistant solenoid isolation valve
The ceramic vacuum sensor and venting valve are built right into the body of the VACUU·SELECT controller
The compact unit is easy to install and setup
With its intuitive, application-based interface, the controller offers predefined vacuum processes for all common laboratory applications
In the case of solvent evaporation, it detects the boiling pressure and then holds the pressure level stable using two-point control
| Gamma | Vacuümmeters |
| Nauwkeurigheid | 1 mbar |
| Afmetingen in mm (L x B x H) | 152 x 126 x 108 mm |
| Principe | Ceramic diaphragm (alumina), capacitive, gas indep., absolute pressure |
| Omgevingstemperatuur (opslag) | -10 - 60 °C |
| ATEX-conformiteit | II 3/- G Ex h IIC T4 Gc X Internal Atm. only |
| NRTL-certificatie | Ja |
| Netspanningsbereik 1 | 100 - 230 V |
| Netfrequentie 1 | 50 - 60 Hz |
| Materialen in contact met medium | Alumina ceramics, PPS, fluoroelastomer |
| Bovengrens meetlimiet | 1.080 mbar/hPa |
| Ondergrens meetlimiet | 0,1 mbar/hPa |
| Vacuümsensor | VACUU·SELECT Sensor |
| Vacuümverbinding | PTFE tubing connection 10/8 mm |
| Temperatuurcoëfficiënt | < 0,15 mbar/hPa/0,11 torr /K |
| Beluchtingsventiel | Geïntegreerd, slanguitgang DN 4-5 mm |
| Max. temp. medium bij continue werking | 40 °C |
| Max. temp. medium bij korte duur | 80 °C |
| Materiaal behuizing | Robust plastic housing with good chemical resistance |
| Beschermingsklasse voorzijde | IP 41 |
| Max. stroom voor VACUU·BUS (24V DC) | 4 A |
| Lengte netkabel | 2 m |
| Interface | Ethernet (RJ45): Modbus TCP / USB (Type A): Data transfer, software update, RS-232 (additional adapter required) |
| Materiaal componenten (excl. afdichting) | VACUU·SELECT complete controller built-in version, for VACUU·LAN work stations, with solenoid valve, PVDF/fluoroplastics, 100-230V / 50-60Hz, plug CEE/CH/UK/US/AUS/CN |
| Gewicht | 1,3 kg |
The VACUU·SELECT complete controller provides enhanced process efficiency to applications supported by a vacuum source such as a basic pump or a powerful vacuum network
The VACUU·SELECT controller has you covered
Use manual set-point-control for simple processes, run pre-defined applications at the touch of a button, or create your own application with simple drag-and-drop editing
The controller is available as a benchtop unit, ready for mounting on lab scaffolding, or as a built-in version for lab casework
The integrated controller includes the VACUU·SELECT vacuum controller, a check valve, and a chemical-resistant solenoid isolation valve
The ceramic vacuum sensor and venting valve are built right into the body of the VACUU·SELECT controller
The compact unit is easy to install and setup
With its intuitive, application-based interface, the controller offers predefined vacuum processes for all common laboratory applications
In the case of solvent evaporation, it detects the boiling pressure and then holds the pressure level stable using two-point control
