Jenway SP-800-UV Double Beam Spectrofotometer
SP-800 Series Double-Beam Spectrophotometers
Integrated user interface for local control
Highly stable optics
Variable spectral bandwidth
The SP-800-UV is a UV-Visible double-beam spectrophotometer with a variable spectral bandwidth
The spectrophotometer has an integrated user interface for local control and ease of navigation
The highly stable optics and two detectors measure the sample and reference simultaneously, optimizing measurement accuracy
The SP-800-UV has Measurement Modes: for photometrics, concentration, multiwavelength, spectrum scanning, kinetics, quantitation, DNA, and protein analysis
Up to 10 wavelengths can be measured in the multi-wavelength measurement mode and
quantitation curves can be created by measuring up to 10 standards at 3 different wavelengths
The double-beam spectrophotometer is ideal for quality control, general research, pharmaceutical, biochemical, and clinical laboratory applications
Key Features:
Double-beam spectrophotometer with highly stable optics
Integrated user interface for local control
Variable spectral bandwidth 0.5, 1, 2, 4, and 5 nm
Prism PC Software: included as standard
Extensive range of accessories available
1 year warranty
Improved Optics:
SP-800-UV covers the UV-Visible wavelength range from 190 to 1100 nm with a variable spectral bandwidth ranging from 5 nm down to 0.5 nm using tungsten halogen and deuterium light sources
The range of bandwidths available allows a balance between resolution, accuracy and data precision to be maximized depending on the application, therefore providing a flexible platform to conform to multiple regulatory agencies for a variety of applications, all with one spectrophotometer
Three scan speeds are available enabling scan speeds of 100 to 2000 nm/min to be achieved
With wavelength scan intervals of 0.1, 0.2, 0.5, 1, 2, or 5 nm, the unit can be configured to meet your exact requirements
Instrument Design:
SP-800-UV has an integrated user interface providing local control of the spectrophotometer
With no PC required, this saves money and valuable bench space
The large graphical display is easy to read and enables more information to be displayed, including spectrum and kinetics curves
The user interface can be navigated using soft key navigation, arrow keys or shortcut keys
The spectrophotometer utilizes a research grade monochromator for excellent energy throughput and a silicone photodiode detector
All of this comes packaged in a small footprint double-beam spectrophotometer while still offering a large Sample Chamber: that enables an 8-position cuvette changer to be fitted
Prism PC Software:
All spectrophotometer functions can be controlled by PC
Additional functionality
Increased results storage
Extensive post-measurement tools
Easy to export data
Windows® compatible
Prism PC Software: is supplied as standard and offers additional functionality, extensive post-measurement tools, unlimited results saving, and easy export of data
The Prism PC Software: can be used to fully control the functionality of the spectrophotometer
The Measurement Modes: available in Prism mirror those of the instrument with Measurement Modes: for photometrics, concentration, multi-wavelength, spectrum scanning, kinetics, quantitation, DNA, and protein analysis
Prism has pre-loaded methods for DNA analysis including 260/280 and 260/230 ratios with 320 nm correction
Up to 20 wavelengths can be measured simultaneously in the multi-wavelength measurement mode, and quantitation curves can be created by measuring up to 200 standards.
| Bereik (nm) | 190 - 1.100 nm |
| Lichtbron | Wolfraam-halogeen- en deuteriumlamp |
| Resolutie | 0,1 nm |
| Spectrum | UV-VIS |
| Herhaalbaarheid | ± 0,2 nm |
| Nauwkeurigheid | ± 0,3 nm |
| Spectrale bandbreedte | 0,5 - 5 nm |
SP-800 Series Double-Beam Spectrophotometers
Integrated user interface for local control
Highly stable optics
Variable spectral bandwidth
The SP-800-UV is a UV-Visible double-beam spectrophotometer with a variable spectral bandwidth
The spectrophotometer has an integrated user interface for local control and ease of navigation
The highly stable optics and two detectors measure the sample and reference simultaneously, optimizing measurement accuracy
The SP-800-UV has Measurement Modes: for photometrics, concentration, multiwavelength, spectrum scanning, kinetics, quantitation, DNA, and protein analysis
Up to 10 wavelengths can be measured in the multi-wavelength measurement mode and
quantitation curves can be created by measuring up to 10 standards at 3 different wavelengths
The double-beam spectrophotometer is ideal for quality control, general research, pharmaceutical, biochemical, and clinical laboratory applications
Key Features:
Double-beam spectrophotometer with highly stable optics
Integrated user interface for local control
Variable spectral bandwidth 0.5, 1, 2, 4, and 5 nm
Prism PC Software: included as standard
Extensive range of accessories available
1 year warranty
Improved Optics:
SP-800-UV covers the UV-Visible wavelength range from 190 to 1100 nm with a variable spectral bandwidth ranging from 5 nm down to 0.5 nm using tungsten halogen and deuterium light sources
The range of bandwidths available allows a balance between resolution, accuracy and data precision to be maximized depending on the application, therefore providing a flexible platform to conform to multiple regulatory agencies for a variety of applications, all with one spectrophotometer
Three scan speeds are available enabling scan speeds of 100 to 2000 nm/min to be achieved
With wavelength scan intervals of 0.1, 0.2, 0.5, 1, 2, or 5 nm, the unit can be configured to meet your exact requirements
Instrument Design:
SP-800-UV has an integrated user interface providing local control of the spectrophotometer
With no PC required, this saves money and valuable bench space
The large graphical display is easy to read and enables more information to be displayed, including spectrum and kinetics curves
The user interface can be navigated using soft key navigation, arrow keys or shortcut keys
The spectrophotometer utilizes a research grade monochromator for excellent energy throughput and a silicone photodiode detector
All of this comes packaged in a small footprint double-beam spectrophotometer while still offering a large Sample Chamber: that enables an 8-position cuvette changer to be fitted
Prism PC Software:
All spectrophotometer functions can be controlled by PC
Additional functionality
Increased results storage
Extensive post-measurement tools
Easy to export data
Windows® compatible
Prism PC Software: is supplied as standard and offers additional functionality, extensive post-measurement tools, unlimited results saving, and easy export of data
The Prism PC Software: can be used to fully control the functionality of the spectrophotometer
The Measurement Modes: available in Prism mirror those of the instrument with Measurement Modes: for photometrics, concentration, multi-wavelength, spectrum scanning, kinetics, quantitation, DNA, and protein analysis
Prism has pre-loaded methods for DNA analysis including 260/280 and 260/230 ratios with 320 nm correction
Up to 20 wavelengths can be measured simultaneously in the multi-wavelength measurement mode, and quantitation curves can be created by measuring up to 200 standards.
