IKA STARVISC 200-2.5 control Viscositeitsmeter
Measure viscosity and display it, even during product development: the new IKA STARVISC 200-2.5 control torque-measuring stirrer makes it possible
The result can be read in real-time on the display
STARVISC therefore has a broad range of applications
This is particularly helpful during product development: STARVISC already clearly indicates while running research programmes as to whether the stirred substance can be used as desired
High-precision measurement
STARVISC measures in a highly precise way and does this even during the manufacturing process
Samples no longer have to be taken separately
Viscosity calculation: A viscosity calculation can be carried out immediately via a userfriendly menu
Removable control unit: The modern TFT display is removable. This means that STARVISC can also be controlled from a safe distance
Powerful stirrer: Even highly viscous substances can be intensively stirred using the powerful STARVISC stirrer
| Stirring quantity max. per stirring position (H2O) [l] | 100 |
| Motor rating input [W] | 130 |
| Motor rating output [W] | 84 |
| Motor principle | Brushless DC |
| Speed display | TFT |
| Speed range [rpm] | 0/6 - 2000 |
| Reversible direction of rotation | no |
| Intermittent operation | yes |
| Viscosity max. [mPas] | 100000 |
| Output max. at stirring shaft [W] | 84 |
| Permissible ON time [%] | 100 |
| Torque max. at stirring shaft [Ncm] | 200 |
| Torque I max. [Ncm] | 200 |
| Torque II max. [Ncm] | 40 |
| Speed range I (50 Hz) [rpm] | 6 - 400 |
| Speed range II (50 Hz) [rpm] | 30 - 2000 |
| Speed range I (60 Hz) [rpm] | 6 - 400 |
| Speed range II (60 Hz) [rpm] | 30 - 2000 |
| Speed adjustment | stepless |
| Setting accuracy speed [rpm] | ±1 |
| Deviation of speed measurement n > 300rpm [%] | ±1 |
| Deviation of speed measurement n < 300rpm [rpm] | ±3 |
| Stirring element fastening | chuck |
| Connection for ext. temperature sensor | PT1000 |
| Temperature display | yes |
| Plug-in coupling (Ø) [mm] | 10 |
| Chuck range diameter [mm] | 0.5 - 10 |
| Hollow shaft (push-through - when stopped) | no |
| Fastening on stand | extension arm |
| Extension arm diameter [mm] | 16 |
| Extension arm length [mm] | 220 |
| Torque display | yes |
| Nominal torque [Nm] | 2 |
| Torque measurement | yes |
| Deviation of torque measurement I [Ncm] | ±2.5 |
| Deviation of torque measurement II [Ncm] | ±2.5 |
| Timer | yes |
| Timer display | TFT |
| Time setting range [min] | 1 - 6000 |
| Temperature measuring range [°C] | -10 - +350 |
| Temperature measurement resolution [K] | 0.1 |
| Accuracy of temperature measurement [K] | ±0.5 + tolerance PT1000 (DIN EN 60751 Class A) |
| Limit deviation temperature sensor [K] | ≤ ± (0.15 + 0.002xITI) |
| Housing material | alu-cast coating / thermoplastic polymer |
| Clean room qualified | no |
| Explosion proofed | no |
| Communication distance (depend onbuilding) max. [m] | 150 |
| Dimensions (W x H x D) [mm] | 91 x 395 x 231 |
| Weight [kg] | 5.9 |
| Permissible ambient temperature [°C] | 5 - 40 |
| Permissible relative humidity [%] | 80 |
| Protection class according to DIN EN 60529 | IP 40 |
| RS 232 interface | yes |
| USB interface | yes |
| Analog output | no |
| Voltage [V] | 230 |
| Frequency [Hz] | 50/60 |
| Power input [W] | 130 |
Measure viscosity and display it, even during product development: the new IKA STARVISC 200-2.5 control torque-measuring stirrer makes it possible
The result can be read in real-time on the display
STARVISC therefore has a broad range of applications
This is particularly helpful during product development: STARVISC already clearly indicates while running research programmes as to whether the stirred substance can be used as desired
High-precision measurement
STARVISC measures in a highly precise way and does this even during the manufacturing process
Samples no longer have to be taken separately
Viscosity calculation: A viscosity calculation can be carried out immediately via a userfriendly menu
Removable control unit: The modern TFT display is removable. This means that STARVISC can also be controlled from a safe distance
Powerful stirrer: Even highly viscous substances can be intensively stirred using the powerful STARVISC stirrer
