IKA Screening System Package (6 cells) Electrochemiekit
The IKA Screening System is perfectly suited for constant current electrosynthesis in “multibatch” mode
The package with 6 divided batch cells enables you to quickly carry out research on multiple electroconversions at the same time
In addition, you can combine the system with other equipment in the laboratory
Six divided cells can be operated in parallel within the Screening System, if double cells are used
These divided reaction cells consist of a reaction block, which requires separate electrode compartments
These are connected by a glass frit
Thus, an electrochemical reaction takes place, but the reaction liquids remain separate
That prevents the mixture of oxidized and reduced liquid
This is of particular interest if the product formed is not stable towards the counter electrode
Up to 6 divided cells can be operated simultaneously and individually
Synthesize sufficient quantities for GC, LC or NMR analysis processes
Separate control and pre-set for each cell
Easy testing of identical or differing electrolysis runs
Fast identification of ideal process parameters
Digital recording of test parameters
Simultaneous mixing and heating
Full temperature control (PT 1000) using heat block
Control and automation via Labworldsoft 6.0
Time and resources savings
| Diameter [mm] | 170 |
| Volume max. [l] | 0.130 |
| Material in contact with medium | PTFE |
| Number of chambers for vials | 6 |
| Depth [mm] | 60 |
| Weight [kg] | 26.9 |
| Permissible ambient temperature [°C] | 5 - 200 |
| RS 232 interface | yes |
| USB interface | no |
| Analog output | yes |
| Voltage [V] | 230 / 115 |
| Frequency [Hz] | 50/60 |
The IKA Screening System is perfectly suited for constant current electrosynthesis in “multibatch” mode
The package with 6 divided batch cells enables you to quickly carry out research on multiple electroconversions at the same time
In addition, you can combine the system with other equipment in the laboratory
Six divided cells can be operated in parallel within the Screening System, if double cells are used
These divided reaction cells consist of a reaction block, which requires separate electrode compartments
These are connected by a glass frit
Thus, an electrochemical reaction takes place, but the reaction liquids remain separate
That prevents the mixture of oxidized and reduced liquid
This is of particular interest if the product formed is not stable towards the counter electrode
Up to 6 divided cells can be operated simultaneously and individually
Synthesize sufficient quantities for GC, LC or NMR analysis processes
Separate control and pre-set for each cell
Easy testing of identical or differing electrolysis runs
Fast identification of ideal process parameters
Digital recording of test parameters
Simultaneous mixing and heating
Full temperature control (PT 1000) using heat block
Control and automation via Labworldsoft 6.0
Time and resources savings
