Ika S 65 KD – G 65 F Dispersing tool
Dispersing tool for the disperser T 65 basic/digital
Type of sealing and bearing: Ball-bearing with PTFE sealing and FFKM O-ring
Product-touching material: AISL 316L, PTFE, FFKM
Suitable for solvents: Yes
Sterilizable: all methods (except ball bearing)
Suitable for vacuum: Yes
Max
working temperature [°C]: 180
Shaft length [mm]: 520
Diameter stator/rotor [mm]: 65/58
Gap between [mm]: 0.5
Recommend emersion depth [mm]: 92 - 450
Recommend working range [ml]: 2, 000 - 30, 000
| Geschikt voor | T 65 basic; T 65 digital | |||||||||||||||||||||||||||||||||||||
| Werkbereik | 2 - 30 L | |||||||||||||||||||||||||||||||||||||
| Technische data |
| Volume range (H2O) [l] | 2 - 30 |
| Stator diameter [mm] | 65 |
| Rotor diameter [mm] | 58 |
| Gap between rotor and stator [mm] | 0.5 |
| allowable Speed max. [rpm] | 9500 |
| Circumferential speed max. [m/s] | 28.8 |
| Immersion depth [mm] | 80 - 450 |
| Shaft length [mm] | 520 |
| Material in contact with medium | FFPM, PTFE, AISI316L |
| pH range | 2 - 13 |
| Suitable for solvents | Nee |
| Suitable for abrasive substances | Nee |
| Working temperature max. [°C] | 180 |
| Sterilization methods | wet chemical |
| Vacuum [mbar] | 100 |
| Ultimate fineness, suspensions [µm] | 5 - 20 |
| Ultimate fineness, emulsions [µm] | 1 - 10 |
| Weight [kg] | 4.24 |
| Permissible ambient temperature [°C] | 5 - 40 |
Dispersing tool for the disperser T 65 basic/digital
Type of sealing and bearing: Ball-bearing with PTFE sealing and FFKM O-ring
Product-touching material: AISL 316L, PTFE, FFKM
Suitable for solvents: Yes
Sterilizable: all methods (except ball bearing)
Suitable for vacuum: Yes
Max
working temperature [°C]: 180
Shaft length [mm]: 520
Diameter stator/rotor [mm]: 65/58
Gap between [mm]: 0.5
Recommend emersion depth [mm]: 92 - 450
Recommend working range [ml]: 2, 000 - 30, 000
