IKA S 10 N – 5 G Dispergeerelement
Suitable for dispersing instrument T 10 basic and T 10 standard
Working range: 0,5
10 ml
Stator diameter: 5 mm
Immersion depth: 20
75 mm
Materials in contact with medium: PTFE, AISI 316L
Suitable for solvents: yes
Max
temperature: 180 °C
Sterilization methods: all methods
| Volume range (H2O) [l] | 0.0005 - 0.010 |
| Stator diameter [mm] | 5 |
| Rotor diameter [mm] | 3.8 |
| Gap between rotor and stator [mm] | 0.1 |
| Circumferential speed max. [m/s] | 6 |
| Immersion depth [mm] | 20 - 75 |
| Shaft length [mm] | 92 |
| Material in contact with medium | PTFE, AISI 316L |
| pH range | 2 - 13 |
| Suitable for solvents | yes |
| Suitable for abrasive substances | yes |
| Working temperature max. [°C] | 180 |
| Sterilization methods | all methods |
| Ultimate fineness, suspensions [µm] | 5 - 25 |
| Ultimate fineness, emulsions [µm] | 1 - 10 |
| Weight [kg] | 0.086 |
| Permissible ambient temperature [°C] | 5 - 40 |
Suitable for dispersing instrument T 10 basic and T 10 standard
Working range: 0,5
10 ml
Stator diameter: 5 mm
Immersion depth: 20
75 mm
Materials in contact with medium: PTFE, AISI 316L
Suitable for solvents: yes
Max
temperature: 180 °C
Sterilization methods: all methods
Downloads
ika-dispergeerelementen-brochure-en.pdf
