15-position digital magnetic hotplate stirrer, designed for synchronous heating and stirring
The magnetic
coil technology provides noiseless and consistent stirring on all positions
The surface temperature is infinitely adjustable up to 120 °C, producing a maximum medium temperature of 70 °C (depending on the used vessel)
Speed remains constant, even when load changes.
Homogeneous temperature distribution across the heating plate
Adjustable reverse operation
Eco-mode for a low self-warming of the surface
Wear free magnetic coils
Error code display
Easy operation with touch keypad
Suitable for continuous operation
Speed range: 0 - 1000 rpm
Afmetingen plaat | 270 x 495 mm | |||||||||||||||||||||||||||||||||||||||||||
Max. volume vloeistof | 0,4 | |||||||||||||||||||||||||||||||||||||||||||
Rotatiesnelheid (tpm) | 0 - 1.000 rpm | |||||||||||||||||||||||||||||||||||||||||||
Verwarming (ja/nee) | Ja | |||||||||||||||||||||||||||||||||||||||||||
Verwarmingstemperatuur | 0 - 120 °C | |||||||||||||||||||||||||||||||||||||||||||
Verwarmingsvermogen | 580 W | |||||||||||||||||||||||||||||||||||||||||||
Technische data |
Number of stirring positions | 15 |
Stirring position distance [mm] | 90 |
Speed deviation of individual stirring positions [%] | 0 |
Stirring quantity max. per stirring position (H2O) [l] | 0.4 |
Speed adjustment | 10 RPM Steps |
Speed range [rpm] | 0 - 1000 |
Stirring bar length [mm] | 25 - 30 |
Heat output [W] | 580 |
Heating temperature range [°C] | room temp. - 120 |
Heat control | LED |
Heating rate heating plate [K/min] | 3 |
Adjustable safety circuit [°C] | 50 - 150 |
Set-up plate material | Aluminium alloy |
Set-up plate dimensions [mm] | 270 x 495 |
Dimensions (W x H x D) [mm] | 280 x 60 x 610 |
Weight [kg] | 10.5 |
Permissible ambient temperature [°C] | 5 - 40 |
Permissible relative humidity [%] | 80 |
Protection class according to DIN EN 60529 | IP 40 |
Voltage [V] | 230 |
Frequency [Hz] | 50/60 |
Power input [W] | 620 |
15-position digital magnetic hotplate stirrer, designed for synchronous heating and stirring
The magnetic
coil technology provides noiseless and consistent stirring on all positions
The surface temperature is infinitely adjustable up to 120 °C, producing a maximum medium temperature of 70 °C (depending on the used vessel)
Speed remains constant, even when load changes.
Homogeneous temperature distribution across the heating plate
Adjustable reverse operation
Eco-mode for a low self-warming of the surface
Wear free magnetic coils
Error code display
Easy operation with touch keypad
Suitable for continuous operation
Speed range: 0 - 1000 rpm
