IKA MATRIX Orbital Delta FP Schudincubator
The IKA Matrix Orbital FP is part of a new and powerful product family of thermoshakers available
IKA Matrix Orbital FP mixes, heats and has a universal holder for microtiter plates
Whether its blood samples, pharmaceutical agents, DNA/RNA samples or ELISA assays – samples with even the smallest volumes mix reliably and completely in all laboratory applications
No cross-contamination and an optimal mixing result
In addition, IKA Matrix Orbital FP comes with numerous user-friendly features:
Large and clear display with a convenient menu structure allows for intuitive operation
Stable quick lock for fast and easy change of inserts and attachments as well as automatic attachment detection
Speeds of up to 2,000 rpm and shaker diameter of 3 mm ensure the liquid mixes quickly and effectively
Programmable ramps allow for automatic execution of mixing and heating tasks
Smart speed adjustment according to insert, attachment and filling volume
Aluminum die cast housing ensures secure positioning, excellent stability and everyday robustness
| Type of movement | orbital |
| Shaking stroke [mm] | 3 |
| Maximun load [kg] | 0.3 |
| Permissible ON time [%] | 100 |
| Speed min (adjustable) [rpm] | 300 |
| Speed range [rpm] | 0 - 2000 |
| Speed display | TFT |
| Speed deviation [rpm] | ±30 |
| Speed adjustment | 10 RPM Steps |
| Timer | yes |
| Timer display | TFT |
| Time setting min. [s] | 1 |
| Time setting max. [min] | 6000 |
| Operating mode | timer, continuous and program operation |
| Touch function | no |
| Shaking table lock | no |
| Working with microtiter plates | yes |
| Number of microtiter plates | 1 |
| Heating temperature range [°C] | room temp. +4° - 100 |
| Heat output [W] | 100 |
| Heat control | TFT |
| Set temperature resolution [°C] | ±1 |
| Temperature control accuracy [°C] | ±1.0 (@ 20°C … 45°C); ±4.0 |
| Temperature stability [°C] | 0.5 |
| Temperature homogenity [°C] | ±0.5 (@ 20°C ... 45°C); ±1.5 |
| Heating rate [°C/min] | 18 |
| Temperature display | yes |
| Number of PCR plates | 1 |
| Number of Deep Well Plates (DWP) | 1 |
| Dimensions (W x H x D) [mm] | 216 x 147 x 351 |
| Weight [kg] | 9.2 |
| Permissible ambient temperature [°C] | 5 - 40 |
| Permissible relative humidity [%] | 80 |
| Protection class according to DIN EN 60529 | IP 21 |
| RS 232 interface | yes |
| USB interface | yes |
| Bluetooth interface | no |
| WiFi Interface | no |
| Analog output | no |
| Voltage [V] | 100 - 240 |
| Frequency [Hz] | 50/60 |
| Power input [W] | 240 |
| Power input max. [W] | 240 |
| Fuse | 2x T4A 250V |
The IKA Matrix Orbital FP is part of a new and powerful product family of thermoshakers available
IKA Matrix Orbital FP mixes, heats and has a universal holder for microtiter plates
Whether its blood samples, pharmaceutical agents, DNA/RNA samples or ELISA assays – samples with even the smallest volumes mix reliably and completely in all laboratory applications
No cross-contamination and an optimal mixing result
In addition, IKA Matrix Orbital FP comes with numerous user-friendly features:
Large and clear display with a convenient menu structure allows for intuitive operation
Stable quick lock for fast and easy change of inserts and attachments as well as automatic attachment detection
Speeds of up to 2,000 rpm and shaker diameter of 3 mm ensure the liquid mixes quickly and effectively
Programmable ramps allow for automatic execution of mixing and heating tasks
Smart speed adjustment according to insert, attachment and filling volume
Aluminum die cast housing ensures secure positioning, excellent stability and everyday robustness
