PATENTED WORLD FIRST: Safety magnetic stirrer with heating and integrated balance
Clear, multilingual TFT display makes it easy to set all parameters
Integrated temperature control feature enables connection of a temperature probe, placed directly in the medium, to control medium temperature with a high degree of precision
PT 100 temperature sensor is included
The stainless steel composite hot plate with white ceramic coating, reaching a temperature of 340 °C, enables rapid heating and very good chemical resiatance
RS 232 and USB interfaces enable pc control of the magnetic stirrer and documentation of all test parameters
"Lock" function prevents inadvertent changes of speed and temperature settings
As a safety feature, the current temperature is displayed when the unit is switched off but surface is still hot
Below 50 °C the display turns off automatically
BNC socket for connection of a pH electrode
Adjustable temperature control mode: rapid heating and very accurate temperature control
Dual sensor for simultaneous control of heat transfer fluid temperature and medium temperature
Timer and countdown functions
Display of viscosity change trend
Detached magnet detection
Intermittent operation
Several modes of operation available
Safety circuit adjustable from 50 to 380°
Transparent protective cover included
Error code display for easy troubleshooting
Exact temperature and speed adjustment by means of digital display - even when function switched off
Suitable for unsupervised operation
Sealed casing (IP 42) ensures a long service life
Automatic switch-off of the heating function if the connected external temperature sensor is not immersed in the medium
Function selectable, timeout time adjustable (Error 5)
Afmetingen plaat | Ø 135 mm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Diameter plaat (Ø) | 135 mm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. volume vloeistof | 20 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Rotatiesnelheid (tpm) | 50 - 1.700 rpm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Verwarming (ja/nee) | Ja | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Verwarmingstemperatuur | 0 - 340 °C | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Verwarmingsvermogen | 600 W | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Technische data |
Number of stirring positions | 1 |
Stirring quantity max. per stirring position (H2O) [l] | 20 |
Motor rating output [W] | 9 |
Direction of rotation | right |
Speed display set-value | TFT |
Speed display actual-value | TFT |
Speed adjustment | Turning kNeeb |
Speed range [rpm] | 50 - 1700 |
Setting accuracy speed [rpm] | 10 |
Stirring bar length [mm] | 20 - 80 |
Self-heating of the set-up plate by max. stirring (RT | 22°C/duration |
Heat output [W] | 600 |
Temperature display set-value | TFT |
Temperature display actual-value | TFT |
Temperature unit | °C / °F |
Heating temperature range [°C] | Room temp. + device self heating - 340 |
Heat control | Turning kNeeb |
Temperature setting range [°C] | 0 - 340 |
Temperature setting resolution of heating plate [K] | 0.1 |
Connection for ext. temperature sensor | PT100/PT1000 (dual sensor) |
Characteristics in the medium with temperature sensor | 1l M50 Oil at H1500 |
Temperature medium max. [°C] | 270 |
Heating rate medium [K/min] | 7 |
Temperature setting resolution of medium [K] | 0.1 |
Adjustable safety circuit [°C] | 50 - 380 |
Set-up plate material | technical enamel |
Set-up plate dimensions [mm] | Ø 135 |
Automatic reverse rotation | Nee |
Intermittent mode | Ja |
Viscosity trend measurement | Ja |
Break detection stirring bar | Ja |
Timer | Ja |
pH measurement | Ja / BNC socket female |
Graph function | Ja |
Programs | Ja |
Sensor in medium detection (Error 5) | Ja |
Weighing function | Ja |
Weighing range [g] | 10-5000 |
Weighing accuracy | ±(0.3%+2) g |
Load capacity weighing function max. [kg] | 5 |
Dimensions (W x H x D) [mm] | 160 x 85 x 270 |
Weight [kg] | 2.7 |
Permissible ambient temperature [°C] | 5 - 40 |
Permissible relative humidity [%] | 80 |
Protection class according to DIN EN 60529 | IP 42 |
RS 232 interface | Ja |
USB interface | Ja |
Analog output | Nee |
Voltage [V] | 220 - 240 |
Frequency [Hz] | 50/60 |
Power input [W] | 650 |
PATENTED WORLD FIRST: Safety magnetic stirrer with heating and integrated balance
Clear, multilingual TFT display makes it easy to set all parameters
Integrated temperature control feature enables connection of a temperature probe, placed directly in the medium, to control medium temperature with a high degree of precision
PT 100 temperature sensor is included
The stainless steel composite hot plate with white ceramic coating, reaching a temperature of 340 °C, enables rapid heating and very good chemical resiatance
RS 232 and USB interfaces enable pc control of the magnetic stirrer and documentation of all test parameters
"Lock" function prevents inadvertent changes of speed and temperature settings
As a safety feature, the current temperature is displayed when the unit is switched off but surface is still hot
Below 50 °C the display turns off automatically
BNC socket for connection of a pH electrode
Adjustable temperature control mode: rapid heating and very accurate temperature control
Dual sensor for simultaneous control of heat transfer fluid temperature and medium temperature
Timer and countdown functions
Display of viscosity change trend
Detached magnet detection
Intermittent operation
Several modes of operation available
Safety circuit adjustable from 50 to 380°
Transparent protective cover included
Error code display for easy troubleshooting
Exact temperature and speed adjustment by means of digital display - even when function switched off
Suitable for unsupervised operation
Sealed casing (IP 42) ensures a long service life
Automatic switch-off of the heating function if the connected external temperature sensor is not immersed in the medium
Function selectable, timeout time adjustable (Error 5)
