IKA C 1 Package 3/10 Calorimeter
The C 1 static jacket oxygen bomb calorimeter provides a high degree of automation and has the smallest calorimeter footprint available
It operates according to DIN 51900 and ISO 1928
The temperature readings are analyzed according to the classical isoperibol method of Regnault Pfaundler
With the C 1 package 3/10 including C 1.20 water heater it is possible to operate the C 1 with drinking-quality tap water in a temperature range of 5 °C to 25 °C (water temperature 21 °C: measuring mode 30 °C)
A chiller is no longer required
The C 1.20 heater serves to maintain the correct temperature of the tap water, which must be connected to the heater at a maximum pressure of 6 bar/0.6 MPa
C 25 pressure regulating gauge is recommended as an accessory if the pressure is higher or cannot be maintained
Scope of delivery
C 1 calorimeter
C 1.10 combustion chamber
C 1.20 water heater
The scope of delivery includes all parts necessary to set up the unit
Additionally it includes wear parts and consumables for the first approximately 500 experiments including 25 calibrations
| Measuring range max. [J] | 40000 |
| Measuring mode adiabatic 22°C | no |
| Measuring mode dynamic 22°C | no |
| Measuring mode isoperibol 22°C | no |
| Measuring mode static jacket 22°C | yes |
| Measuring mode adiabatic 25°C | no |
| Measuring mode dynamic 25°C | no |
| Measuring mode isoperibol 25°C | no |
| Measuring mode static jacket 25°C | no |
| Measuring mode adiabatic 30°C | no |
| Measuring mode dynamic 30°C | no |
| Measuring mode isoperibol 30°C | no |
| Measuring mode static jacket 30°C | yes |
| Measuring mode double dry (ISO 1928) | no |
| Measurements/h static jacket | 4 |
| Reproducibility static jacke (1g benzoic acid NBS39i) [%RSD] | 0.15 |
| Touchscreen | no |
| Working temperature [°C] | 20 - 30 |
| Temperature measurement resolution [K] | 0.0001 |
| Cooling medium temperature [°C] | 18 - 29 |
| Cooling medium permissible operating pressure [bar] | 1.5 |
| Cooling medium | tap water |
| Type of cooling | flow |
| Flow rate [l/h] | 50 - 60 |
| Rec. flow rate at 18°C [l/h] | 55 |
| Oxygen operating pressure max. [bar] | 40 |
| Interface scale | RS232 |
| Interface printer | RS232 |
| Interface PC | RS232 |
| Interface test rack | no |
| Interface ext. monitor | no |
| Interface ext. keyboard | no |
| Oxygen filling | yes |
| Degasification | yes |
| Decomposition detection | no |
| Decomposition vessel C 5010 | no |
| Decomposition vessel C 5012 | no |
| Decomposition vessel C 7010 | no |
| Decomposition vessel C 7012 | no |
| Decomposition vessel C 6010 | no |
| Decomposition vessel C 6012 | no |
| Decomposition vessel C 62 | no |
| Decomposition vessel integrated | yes |
| Analysis according to DIN 51900 | yes |
| Analysis according to ASTM D240 | no |
| Analysis according to ASTM D4809 | no |
| Analysis according to ASTM D1989 | no |
| Analysis according to ASTM D5468 | no |
| Analysis according to ASTM D5865 | no |
| Analysis according to ASTM E711 | no |
| Analysis according to ISO 1928 | yes |
| Analysis according to BS 1016 | no |
| Dimensions (W x H x D) [mm] | 290 x 280 x 300 |
| Weight [kg] | 15 |
| Permissible ambient temperature [°C] | 5 - 40 |
| Permissible relative humidity [%] | 80 |
| Protection class according to DIN EN 60529 | IP 20 |
| RS 232 interface | yes |
| USB interface | yes |
| Analog output | no |
| Voltage [V] | 100 - 240 |
| Frequency [Hz] | 50/60 |
| Power input [W] | 120 |
The C 1 static jacket oxygen bomb calorimeter provides a high degree of automation and has the smallest calorimeter footprint available
It operates according to DIN 51900 and ISO 1928
The temperature readings are analyzed according to the classical isoperibol method of Regnault Pfaundler
With the C 1 package 3/10 including C 1.20 water heater it is possible to operate the C 1 with drinking-quality tap water in a temperature range of 5 °C to 25 °C (water temperature 21 °C: measuring mode 30 °C)
A chiller is no longer required
The C 1.20 heater serves to maintain the correct temperature of the tap water, which must be connected to the heater at a maximum pressure of 6 bar/0.6 MPa
C 25 pressure regulating gauge is recommended as an accessory if the pressure is higher or cannot be maintained
Scope of delivery
C 1 calorimeter
C 1.10 combustion chamber
C 1.20 water heater
The scope of delivery includes all parts necessary to set up the unit
Additionally it includes wear parts and consumables for the first approximately 500 experiments including 25 calibrations
