VOL-SP-2.1 is an optional spindle for an extended viscosity range
It is especially suitable for sample volumes of 2.1 ml
It is required to use the 2.1 ml chamber VOL-C-RTD-2.1 in combination with the VOL-SP-2.1 spindle
The chamber is available as accessory
Spindle geometry | Cylinder |
Connection | Thread M2.5 LH |
Hook connector | yes |
Diameter [mm] | 8.7 |
Immersion depth [mm] | 19.5 |
Spindle length [mm] | 42 |
Sample volume [ml] | 2.1 |
Flow Jacket | yes |
Mounting Bracket | yes |
Sample container | : Specified chamber |
Working temperature max. [°C] | 100 |
Viscosity Accuracy (FSR) [%] | 2 |
Viscosity Repeatibility (FSR) [%] | 0.2 |
Min. FSR match ROTAVISC lo-vi [mPa.s] | 585.8 |
Max. FSR match ROTAVISC lo-vi [mPa.s] | 117163 |
Min. FSR match ROTAVISC me-vi [mPa.s] | 6250 |
Max. FSR match ROTAVISC me-vi [mPa.s] | 1250000 |
Min. FSR match ROTAVISC hi-vi I [mPa.s] | 12500 |
Max. FSR match ROTAVISC hi-vi I [mPa.s] | 2500000 |
Min. FSR match ROTAVISC hi-vi II [mPa.s] | 50000 |
Max. FSR match ROTAVISC hi-vi II [mPa.s] | 10000000 |
Material in contact with medium | stainless steel 1.4404 |
Dimensions (W x H x D) [mm] | 11 x 44 x 11 |
Weight [kg] | 0.007 |
Permissible ambient temperature [°C] | 5 - 40 |
VOL-SP-2.1 is an optional spindle for an extended viscosity range
It is especially suitable for sample volumes of 2.1 ml
It is required to use the 2.1 ml chamber VOL-C-RTD-2.1 in combination with the VOL-SP-2.1 spindle
The chamber is available as accessory
