Ika TWISTER Add-on unit
Add-on unit for existing TWISTER setups
It is supplied without power supply and without accessories
Please check whether the power of your currently used power supply is sufficient to supply the planned number of TWISTER devices:
Up to 2 devices: power supply from TWISTER SET 1 &
2
2 to 4 devices: TW
PWR.1 or power supply from TWISTER SET 3 &
4
4 to 30 devices: TW.PWR.2
| Afmetingen plaat | 124 x 124 mm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Max. volume vloeistof | 5 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Rotatiesnelheid (tpm) | 100 - 3.000 rpm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Verwarming (ja/nee) | Nee | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Technische data |
| Number of stirring positions | 1 |
| Stirring quantity min. per stirring position (H2O) [l] | 0.005 |
| Stirring quantity max. per stirring position (H2O) [l] | 5 |
| Motor rating output [W] | 5 |
| Direction of rotation | right / left |
| Speed display set-value | LED |
| Speed display actual-value | LED |
| Speed adjustment | Touch key |
| Speed range [rpm] | 100 - 3000 |
| Setting accuracy speed [rpm] | 100 |
| Stirring bar length [mm] | 10 - 30 |
| Self-heating of the set-up plate by max. stirring (RT | 22°C/duration |
| Set-up plate material | glass |
| Set-up plate dimensions [mm] | 124 x 124 |
| Automatic reverse rotation | Ja |
| Intermittent mode | Ja |
| Viscosity trend measurement | Ja |
| Time setting min. [s] | 6 |
| Time setting max. [min] | 30 |
| Speed deviation (Nee load,Neeminal voltage, at 1500rpm + 25 °C) [%] | ±2 |
| Modular expandable stirring system (2-30 units) | Ja |
| Leader- follower operation (minimum 2 units required, leader unit controls synchroNeeusly follower unit) | Ja |
| Vessel detection (optional activated/deactivated) | Ja |
| Motor acceleration rise time adjustment (Function available with additional accessories) | Nee |
| Definition of up to 6 stirring groups (Function available with additional accessories) | Nee |
| Dimensions (W x H x D) [mm] | 135 x 24 x 135 |
| Weight [kg] | 0.6 |
| Permissible ambient temperature [°C] | 5 - 40 |
| Permissible relative humidity [%] | 80 |
| Protection class according to DIN EN 60529 | IP 66 |
| USB interface | optional |
| Voltage [V] | 100 - 240 |
| Frequency [Hz] | 50/60 |
| Power input [W] | 10 |
| Power input standby [W] | 2 |
| DC Voltage [V=] | 24 |
| Current consumption [mA] | 400 |
Add-on unit for existing TWISTER setups
It is supplied without power supply and without accessories
Please check whether the power of your currently used power supply is sufficient to supply the planned number of TWISTER devices:
Up to 2 devices: power supply from TWISTER SET 1 &
2
2 to 4 devices: TW
PWR.1 or power supply from TWISTER SET 3 &
4
4 to 30 devices: TW.PWR.2
