IKA S 25 N – 18 G Dispergeerelement
Suitable for dispersing instrument T 25 digital
Working range: 10
1.500 ml
Immersion depth: 40
165 mm
Materials in contact with medium: PTFE, AISI 316L
Suitable for solvents: yes
Max
temperature: 180 °C
Sterilization methods: all methods
| Volume range (H2O) [l] | 0.010 - 1.5 |
| Stator diameter [mm] | 18 |
| Rotor diameter [mm] | 12.7 |
| Gap between rotor and stator [mm] | 0.3 |
| allowable Speed max. [rpm] | 25000 |
| Circumferential speed max. [m/s] | 16.6 |
| Immersion depth [mm] | 40 - 165 |
| Shaft length [mm] | 194 |
| Material in contact with medium | PTFE, AISI 316L |
| pH range | 2 - 13 |
| Suitable for solvents | yes |
| Suitable for abrasive substances | yes |
| Working temperature max. [°C] | 180 |
| Sterilization methods | all methods |
| Ultimate fineness, suspensions [µm] | 10 - 50 |
| Ultimate fineness, emulsions [µm] | 1 - 10 |
| Weight [kg] | 0.4 |
| Permissible ambient temperature [°C] | 5 - 40 |
Suitable for dispersing instrument T 25 digital
Working range: 10
1.500 ml
Immersion depth: 40
165 mm
Materials in contact with medium: PTFE, AISI 316L
Suitable for solvents: yes
Max
temperature: 180 °C
Sterilization methods: all methods
Downloads
ika-dispergeerelementen-brochure-en.pdf
