IKA ROLLER 6 digital Rolschudder
Digital roller shaker with 6 rolls provides smooth rocking and rolling action at infinitely adjustable speeds
Used for mixing blood samples, solid and liquid suspensions and viscous samples
The unit can be used with all conventional tubes and cylindrical bottles
Easily removable attachments provide for quick cleaning in case of sample spills
Timer: Countdown, adjustable from 1 s to 99h 59min
Counter: Display of shaking time
Error Code Display
Usable at 4 to 50 °C in incubators
Suitable for continuous operation
Removable rolls enable shaking of larger tubes
Easy operation with keypad
Shaking diameter: 24,5 mm (height)
Speed range: 5
80 rpm
| Type of movement | rolling |
| Permissible ON time [%] | 100 |
| Speed min (adjustable) [rpm] | 5 |
| Speed range [rpm] | 0 - 80 |
| Speed display | 7 segment LED |
| Speed adjustment | 1 RPM steps |
| Timer | yes |
| Timer display | 7 segment LED |
| Time setting min. [s] | 1 |
| Time setting max. [min] | 5999 |
| Operating mode | timer and continuous operation |
| Touch function | no |
| Shaking table lock | no |
| Rolls, number | 6 |
| Rolls, Ø [mm] | 32 |
| Rolls, length [mm] | 327 |
| Working area length [mm] | 350 |
| Rolls, luffing angle fixed [°] | 3 |
| Rolls, max stroke at roll end [mm] | 16 |
| Rolls, changeable, removable | yes |
| Unit stackable | no |
| Shaking platform stackable | no |
| Dimensions (W x H x D) [mm] | 240 x 115 x 545 |
| Weight [kg] | 4 |
| Permissible ambient temperature [°C] | 4 - 50 |
| Permissible relative humidity [%] | 80 |
| Protection class according to DIN EN 60529 | IP 21 |
| RS 232 interface | no |
| USB interface | no |
| Analog output | no |
| Voltage [V] | 100 - 240 |
| Frequency [Hz] | 50/60 |
| Power input [W] | 24 |
| DC Voltage [V=] | 24 |
| Current consumption [mA] | 1000 |
Digital roller shaker with 6 rolls provides smooth rocking and rolling action at infinitely adjustable speeds
Used for mixing blood samples, solid and liquid suspensions and viscous samples
The unit can be used with all conventional tubes and cylindrical bottles
Easily removable attachments provide for quick cleaning in case of sample spills
Timer: Countdown, adjustable from 1 s to 99h 59min
Counter: Display of shaking time
Error Code Display
Usable at 4 to 50 °C in incubators
Suitable for continuous operation
Removable rolls enable shaking of larger tubes
Easy operation with keypad
Shaking diameter: 24,5 mm (height)
Speed range: 5
80 rpm
