Ika RCT 5 digital
The new magnetic stirrer RCT 5 digital with 850 W offers significantly more power making it an ideal device for demanding stirring tasks up to 20 l
Multifunctional menu
Whether determining the direction of rotation, timer functions or sequence programming - the stirring process can be programmed individually from beginning to end
In this way, the reaction runs reliably and safely even without monitoring
Scratch-resistant ceramic coating
RCT 5 digital has a rectangular set-up plate with a white, ceramic coating
It is less scratch-prone than conventional magnetic stirrer plates
Safety features
The display is made of chemical resistant and hardened glass which increases the safety of the user
In addition, a symbol in the display warns in case of a hot surface and therefore protects from burnings
The safety circuit can be adjusted up to 370 °C
Automatic switch-off of the heating function, if the connected external temperature sensor is not immersed in the medium
Function selectable, timeout time adjustable (Error 5)
| Afmetingen plaat | 137 x 137 mm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Max. volume vloeistof | 20 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Rotatiesnelheid (tpm) | 50 - 1.500 rpm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Verwarming (ja/nee) | Ja | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Verwarmingstemperatuur | 0 - 310 °C | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Verwarmingsvermogen | 850 W | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Technische data |
| Number of stirring positions | 1 |
| Stirring quantity max. per stirring position (H2O) [l] | 20 |
| Motor rating output [W] | 9 |
| Direction of rotation | right / left |
| Speed display set-value | LCD |
| Speed display actual-value | LCD |
| Speed adjustment | Turning kNeeb |
| Speed range [rpm] | 50 - 1500 |
| Setting accuracy speed [rpm] | 10 |
| Stirring bar length [mm] | 30 - 80 |
| Self-heating of the set-up plate by max. stirring (RT | 22°C/duration |
| Heat output [W] | 850 |
| Temperature display set-value | LCD |
| Temperature display actual-value | LCD |
| Temperature unit | °C / °F |
| Heating temperature range [°C] | Room temp. + device self heating - 310 |
| Heat control | Turning kNeeb |
| Temperature setting range [°C] | 0 - 310 |
| Temperature setting resolution of heating plate [K] | 1 |
| Connection for ext. temperature sensor | PT1000, ETS-D5, ETS-D6 |
| Temperature setting resolution of medium [K] | 1 |
| Adjustable safety circuit [°C] | 50 - 370 |
| Set-up plate material | Aluminum with ceramic coating |
| Set-up plate dimensions [mm] | 137 x 137 |
| Automatic reverse rotation | Ja |
| Intermittent mode | Ja |
| Viscosity trend measurement | Ja |
| Break detection stirring bar | Nee |
| Timer | Ja |
| Timer display | LCD |
| Time setting min. [s] | 1 |
| Time setting max. [min] | 143940 |
| pH measurement | Nee |
| Graph function | Nee |
| Programs | Nee |
| Sensor in medium detection (Error 5) | Ja |
| Weighing function | Nee |
| Set-up plate illuminated | Nee |
| Speed deviation (Nee load,Neeminal voltage, at 1500rpm + 25 °C) [%] | ±2 |
| Heating rate (1l H2O in H1500) [K/min] | 7.5 |
| Heat control accuracy of heating plate (at 100°C) [K] | ±5 |
| Heat control accuracy with ext. PT1000 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C) [K] | ±0.5 |
| Heat control accuracy with ETS-D5 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C) [K] | ±0.5 |
| Heat control accuracy with ETS-D6 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C) [K] | ±0.2 |
| Dimensions (W x H x D) [mm] | 160 x 85 x 270 |
| Weight [kg] | 2.6 |
| Permissible ambient temperature [°C] | 5 - 40 |
| Permissible relative humidity [%] | 80 |
| Protection class according to DIN EN 60529 | IP 42 |
| RS 232 interface | Ja |
| USB interface | Ja |
| Bluetooth interface | Nee |
| Analog output | Nee |
| Voltage [V] | 220 - 230 |
| Frequency [Hz] | 50/60 |
| Power input [W] | 900 |
| Power input standby [W] | 1.6 |
The new magnetic stirrer RCT 5 digital with 850 W offers significantly more power making it an ideal device for demanding stirring tasks up to 20 l
Multifunctional menu
Whether determining the direction of rotation, timer functions or sequence programming - the stirring process can be programmed individually from beginning to end
In this way, the reaction runs reliably and safely even without monitoring
Scratch-resistant ceramic coating
RCT 5 digital has a rectangular set-up plate with a white, ceramic coating
It is less scratch-prone than conventional magnetic stirrer plates
Safety features
The display is made of chemical resistant and hardened glass which increases the safety of the user
In addition, a symbol in the display warns in case of a hot surface and therefore protects from burnings
The safety circuit can be adjusted up to 370 °C
Automatic switch-off of the heating function, if the connected external temperature sensor is not immersed in the medium
Function selectable, timeout time adjustable (Error 5)
