IKA R 50 stirring shaft «high speed»
With the R 50 stirring shaft, the disperser T 50 digital can be converted into a high speed stirrer
This configuration is recommended for applications that require medium to high shearing forces
The dissolver disk design of the mixing head coupled with the high speed results in rapid mixing, dissolving, and disagglomeration
A protective cage is fitted around the mixing head and shaft to ensure operational safety
The dissolver head R 1402 is included in scope of delivery
Alternatively, the mixing head can be changed to a propeller design with the accessory R 1405 in order to facilitate low to medium mixing viscosities under low shear at high speed
Immersion depth: 180 mm
Working range: 0.25 - 30 L
Rotor diameter: 40 mm
Material: stainless steel (AlSl 316L)
| Volume range (H2O) [l] | 0.25 - 30 |
| Rotor diameter [mm] | 40 |
| allowable Speed max. [rpm] | 10000 |
| Circumferential speed max. [m/s] | 23.6 |
| Immersion depth [mm] | 50 - 180 |
| Shaft length [mm] | 323 |
| Material in contact with medium | AISI 316L / AISI 304 |
| pH range | 2 - 13 |
| Suitable for solvents | yes |
| Suitable for abrasive substances | yes |
| Working temperature max. [°C] | 150 |
| Dry Operation | yes |
| Weight [kg] | 1.25 |
| Permissible ambient temperature [°C] | 5 - 40 |
With the R 50 stirring shaft, the disperser T 50 digital can be converted into a high speed stirrer
This configuration is recommended for applications that require medium to high shearing forces
The dissolver disk design of the mixing head coupled with the high speed results in rapid mixing, dissolving, and disagglomeration
A protective cage is fitted around the mixing head and shaft to ensure operational safety
The dissolver head R 1402 is included in scope of delivery
Alternatively, the mixing head can be changed to a propeller design with the accessory R 1405 in order to facilitate low to medium mixing viscosities under low shear at high speed
Immersion depth: 180 mm
Working range: 0.25 - 30 L
Rotor diameter: 40 mm
Material: stainless steel (AlSl 316L)
