IKA O DIN S-1
The open DIN spindle set (O-DINS-1) measures viscosities according to DIN 53019 and can be used with customer-specific vessels
The set includes a single-wall-open-jacket to quickly dive into the sample liquid as well as a coaxial cylinder system for the analysis of the sample at a specific shear rate and shear stress is included
The maximum measurable viscosity is 50 000 mPas
| Spindle geometry | Cylinder |
| Connection | Thread M2.5 LH |
| Hook connector | no |
| Flow Jacket | yes |
| Mounting Bracket | yes |
| Sample container | : Specified chamber |
| Working temperature max. [°C] | 100 |
| Viscosity Accuracy (FSR) [%] | 2 |
| Viscosity Repeatibility (FSR) [%] | 0.2 |
| Min. FSR match ROTAVISC lo-vi [mPa.s] | 6 |
| Max. FSR match ROTAVISC lo-vi [mPa.s] | 50000 |
| Min. FSR match ROTAVISC me-vi [mPa.s] | 61 |
| Max. FSR match ROTAVISC me-vi [mPa.s] | 50000 |
| Min. FSR match ROTAVISC hi-vi I [mPa.s] | 122 |
| Max. FSR match ROTAVISC hi-vi I [mPa.s] | 50000 |
| Min. FSR match ROTAVISC hi-vi II [mPa.s] | 488 |
| Max. FSR match ROTAVISC hi-vi II [mPa.s] | 50000 |
| Material in contact with medium | stainless steel 1.4404 |
| Dimensions (W x H x D) [mm] | 390 x 102 x 310 |
| Weight [kg] | 1.919 |
| Permissible ambient temperature [°C] | 5 - 40 |
The open DIN spindle set (O-DINS-1) measures viscosities according to DIN 53019 and can be used with customer-specific vessels
The set includes a single-wall-open-jacket to quickly dive into the sample liquid as well as a coaxial cylinder system for the analysis of the sample at a specific shear rate and shear stress is included
The maximum measurable viscosity is 50 000 mPas
