IKA LR 5000.3 Reactor vessel
Double-walled stainless steel reactor vessel
For use with the LR-5.ST laboratory reactor
Volume: 5.0 l
Material in contact with medium: AISI 316L
Including stainless steel metal adapter M 16x1 (Male) for connection of temperature hoses or quick connection adapters
| Useable volume max. [ml] | 5000 |
| Working temperature [°C] | -50 - 230 |
| Pressure max. | atmospheric pressure |
| Attainable vacuum [mbar] | 25 |
| Material in contact with medium | AISI 316L |
| Fill level at nominal volume [mm] | 175 |
| Vessel inner diameter [mm] | 200 |
| Vessel outer diameter [mm] | 254 |
| Height (room dimension) [mm] | 289 |
| Width (room dimension) [mm] | 259 |
| Depth (room dimension) [mm] | 254 |
| Flange dimension | DN200 |
| Flange collar diameter [mm] | 204 |
| Bottom shape | Torispherical head |
| Bottom drain | yes |
| Bottom valve | Standard valve |
| Bottom drain outlet inner diameter [mm] | 20 |
| Bottom drain outlet outer diameter [mm] | 25 |
| Bottom drain shape | Straight with olive |
Double-walled stainless steel reactor vessel
For use with the LR-5.ST laboratory reactor
Volume: 5.0 l
Material in contact with medium: AISI 316L
Including stainless steel metal adapter M 16x1 (Male) for connection of temperature hoses or quick connection adapters
