IKA ICC control eco 18 Circulatiebadverwarming
IKA facilitates the configuration of your temperature control system by offering “ready for connection“ packages with all necessary accessories
Package includes
ICC control compact immersion circulator
IB 18 eco plastic bath (size L)
BL.ICC large bridge
total: 338 x 584 x 349 mm
bath opening: 245 x 305 mm *
max
bath opening: 286 x 325 mm **
Immersion depth
85 mm–125 mm
*Dimensions to set plate at the bottom of bath
** Maximum bath opening dimensions at the upper edge of the bath
Max
temperature in the plastic bath (“eco” series): 100°C (water only)
Technical data relates to the temperature control instrument included in the package
| Appliance type | Compact immersion circulators |
| Class designation acc. DIN 12876 | III |
| Identification according to DIN 12876 | FL |
| Heat output [W] | 2000 |
| Working temperature [°C] | room temp. +10K @1000rpm - 150 |
| Operating temperature min. (with external cooling) [°C] | -20 |
| Temperature display | yes |
| Temperature control | PID |
| Working temperature sensor | PT 100 |
| Safety temperature sensor | PT1000 |
| Working temperature display | TFT |
| Safety temperature display | TFT |
| Temperature stability DIN 12876 [K] | ±0.01 |
| Connection for ext. temperature sensor | PT 100 |
| Display resolution [K] | 0.01 |
| Display for operation with ext. sensor | yes |
| Set temperature resolution [K] | ±0.1 |
| Warning function optical | yes |
| Warning function acoustic | yes |
| Warning function excess temperature | yes |
| Warning function insufficient temperature | no |
| Adjustable safety circuit [°C] | 0 - 160 |
| Sub-level protection | yes |
| Over-level protection | yes |
| Pump type | Pressure- / suction pump |
| Pump capacity adjustable | yes |
| Pump pressure max. (0 liters discharge flow) [bar] | 0.3 |
| Pressure pump (suction side) (0 liter flow) [bar] | 0.2 |
| Flow rate max. (0 bar back pressure) [l/min] | 18 |
| Bath depth min. [mm] | 150 |
| Calibration option | yes |
| Appliance fastener | clamp |
| Technical data complies with the standard | DIN 12876 |
| Permissible ON time [%] | 100 |
| Dimensions (W x H x D) [mm] | 145 x 340 x 200 |
| Weight [kg] | 11.99 |
| Permissible ambient temperature [°C] | 5 - 40 |
| Permissible relative humidity [%] | 80 |
| Protection class according to DIN EN 60529 | IP 21 |
| RS 232 interface | yes |
| USB interface | yes |
| Voltage [V] | 230 |
| Frequency [Hz] | 50/60 |
| Power input [W] | 2100 |
IKA facilitates the configuration of your temperature control system by offering “ready for connection“ packages with all necessary accessories
Package includes
ICC control compact immersion circulator
IB 18 eco plastic bath (size L)
BL.ICC large bridge
total: 338 x 584 x 349 mm
bath opening: 245 x 305 mm *
max
bath opening: 286 x 325 mm **
Immersion depth
85 mm–125 mm
*Dimensions to set plate at the bottom of bath
** Maximum bath opening dimensions at the upper edge of the bath
Max
temperature in the plastic bath (“eco” series): 100°C (water only)
Technical data relates to the temperature control instrument included in the package
