IKA HELISTAND Electrical stand for ROTAVISC
€1.284,00
IKA HELISTAND Set Electrical stand incl. T-spindle set
The motorized IKA HELISTAND allows you to measure the viscosity of highly viscous samples with a high level of reliability
It moves the mounted viscometer and its rotating body slowly and uniformly up and down in the sample
Highly viscous samples such as creams, pastes, paints and gelatin cause a static viscometer to run empty
These substances are so viscous that they are forced to the edge by the rotational movements
An air channel is created around the rotating body, which is why the acting torque is then no longer meaningful
The IKA HELISTAND can prevent this by means of slow movements, up and down
Combined with the included T-spindles for non-flowing samples, you can thus acquire meaningful viscosity measurements
Other voltage variants available (220 - 230 V / 100 - 115 V)
| Stroke max. | 142 mm |
| Diameter | 16 mm |
| Dynamic load | 3.2 kg |
| Overload protection | yes |
| Height adjustable safety switch | yes |
| Dimensions (W x H x D) | 351 x 330 x 262 mm |
| Weight | 6 kg |
| Permissible ambient temperature | 0 - 40 °C |
| Permissible relative humidity | 80 % |
| Protection class according to DIN EN 60529 | IP 40 |
| Voltage | 220 - 230 V |
| Frequency | 50/60 Hz |
| Power input | 7 W |
| Power input max. | 7 W |
| Power input standby | 0 W |
The motorized IKA HELISTAND allows you to measure the viscosity of highly viscous samples with a high level of reliability
It moves the mounted viscometer and its rotating body slowly and uniformly up and down in the sample
Highly viscous samples such as creams, pastes, paints and gelatin cause a static viscometer to run empty
These substances are so viscous that they are forced to the edge by the rotational movements
An air channel is created around the rotating body, which is why the acting torque is then no longer meaningful
The IKA HELISTAND can prevent this by means of slow movements, up and down
Combined with the included T-spindles for non-flowing samples, you can thus acquire meaningful viscosity measurements
Other voltage variants available (220 - 230 V / 100 - 115 V)
