Ika HBR 4 control
The heating bath is noted for:
Cylindrical bath shape
Heating elements integrated into the bath base
Heat transfer media can be low-viscous oil (50 mPas) or water (H2O)
Useful volume: approx
4 l
Heat output: 1000 W
Two carry handles
Infinitely variable safety temperature limiter according to DIN 12877
Double-jacketed mantle protection against burns -
Digital display for target, actual and safety temperatures as well as speed
Integrated magnetic stirrer drive to circulate the tempering fluid, allowing for better heat distribution in the bath
RS 232 interface
Heating bath can be operated with an external temperature sensor for temperature control directly in the medium
| Homogeniteit | ±1 K | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Max. volume bad (L) | 4 L | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Temperatuurbereik (°C) | 0 - 200 °C | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Verwarmingsvermogen (W) | 1.000 W | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Vloeistofschudding (ja/nee) | Oui | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Technische data |
| Heat output [W] | 1000 |
| Heating temperature range [°C] | room temp. - 200 |
| Heat control | stepless |
| Set temperature resolution [K] | ±1 |
| Controller oscillation (3 l water / 90 °C) [K] | ±1 |
| Controller oscillation (3l Silicone oil / 50mPas / 150°C) [K] | ±2 |
| Speed display | LCD |
| Speed adjustment | stepless |
| Speed range [rpm] | 150 - 800 |
| Motor rating input [W] | 5 |
| Motor rating output [W] | 1 |
| Filling volume max. [l] | 4 |
| Filling point min. [mm] | 20 |
| Material in contact with medium | stainless steel 1.4301 |
| Connection for ext. temperature sensor | PT1000 |
| Adjustable safety circuit [°C] | 50 - 210 |
| Class designation acc. DIN 12876 | II |
| Outer diameter [mm] | 250 |
| Inner diameter [mm] | 200 |
| Outer height [mm] | 250 |
| Inner height [mm] | 160 |
| Dimensions (W x H x D) [mm] | 340 x 250 x 340 |
| Weight [kg] | 5.6 |
| Permissible ambient temperature max. [°C] | 40 |
| Permissible relative humidity [%] | 80 |
| Protection class according to DIN EN 60529 | IP 20 |
| RS 232 interface | Ja |
| Voltage [V] | 230 |
| Frequency [Hz] | 50/60 |
| Power input [W] | 1020 |
The heating bath is noted for:
Cylindrical bath shape
Heating elements integrated into the bath base
Heat transfer media can be low-viscous oil (50 mPas) or water (H2O)
Useful volume: approx
4 l
Heat output: 1000 W
Two carry handles
Infinitely variable safety temperature limiter according to DIN 12877
Double-jacketed mantle protection against burns -
Digital display for target, actual and safety temperatures as well as speed
Integrated magnetic stirrer drive to circulate the tempering fluid, allowing for better heat distribution in the bath
RS 232 interface
Heating bath can be operated with an external temperature sensor for temperature control directly in the medium
